Overview
Quick Details
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Model Number:
- DGLB6500SE
- Rated Voltage:
- 120, 220, 230,240V
- Rated Current:
- 22.7A
- Speed:
- 3000/3600rpm
- Frequency:
- 50HZ/60HZ
- Color:
- Yellow/Green/White/Green/Red/Orange/Blue
- Type:
- Silent and electric
- Panel:
- Common/digital
- Wheel:
- Solid rubber wheel /universal wheel
- Design:
- New
- Noise:
- low
- Phase:
- Single/three
- Lamps:
- Four Halogen or LED
- Mast:
- Raising and lowing
- Engine type:
- HR186FA/10hp diesel engine
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 168X65X161 cm
- Single gross weight:
- 205.0 kg
- Package Type:
- Packaging details:wooden with plastic film Delivery time: 20 days
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 1 2 - 10 >10 Est. Time(days) 15 20 To be negotiated
Related Products
| Technical Sepcifications | ||
| Model | DGLB6500SE-LED lamp | DGLB6500SE-Halide lamp |
| Mast | ||
| Maximum extention of mast | 4.8m | |
| Raising/lowing mast | Button (Electric) | |
| Stages | 3 | |
| Turing angle | 360 degrees non-continuous | |
| Lamp | ||
| Total power of lamps | 4x50W | 4x1000W |
| Type of lamp | LED lamp | Halide Lamp |
| Light capacity | 4x625000 Lumen | |
| Voltage | 220V | |
| Frequency | 50Hz | |
| Lifetime of lamp | 2000 hours | |
| Working temperature | ≤85℃ | |
| Connection protection index | IP54 | |
| Characteristics of the generator: | ||
| Model | DG6500SE | |
| Frequency(Hz) | 50 | |
| Rated power(KW) | 5.5 | |
| Standby power(KW) | 5 | |
| Engine mdel | HR186FA | |
| Engine speed(RPM) | 3000 | |
| Engine type | Single cylinder, 4-stroke, air-cooled diesel engine | |
| Starting system | Electric start | |
| Alternator | 2-pole, brush | |
| Fuel tank capacity | 16L | |
| Working hours(H) | 8.5 | |
| Control system | Normal panel | |
| Power outlets | 2 | |
| Trailer: | ||
| Stabilier supprts | 4 x Manual | |
| Tire size | 4 inch | |
| Anti-wind capacity | ≤6 | |
| Brakes | Manual | |
| Packing Dimension & Weight: | ||
| Retracted Dimension(cm) | 123×64×101, 159×29×17, 106×56×42 | |
| Gross weight(KGS) | 270 | |
