water well drilling rig
water well drilling rig mobile and lightweight
Product advantage
a.53*59 drillng rod adopted,high rigity and string delivery torque.
b. The machine is equipped with national patent technology--taper clutch,with charactristics.
c.Of string transmission troque,easy operation and free maintenance.
d.for the wich,we use large module planetary gear and add supporting frame,greatly
e.Increasing hoisting and braking ability of the winch .
f.vertical spindle are fixed by four groups of bearings to ensure that therotary machine is
g.Rigid enough for gravel layer and other comples geoloical conditions,
h.Wecan the firstone to equip mud pump with the flow 160L/min in china so that it will
i.Save cost and also make the machine compct,moblie and lightweight.
Unity machine parameter
Drilling depth 200m
Max open hole caliber 300mm
End hole caliber 75mm
Drill rod caliber 60mm
Drillng angle 90~75°
Drilling weight(without power) 975kg
Triangle conveyer belt B950*4 B1700*3
The main machine moving distance 300mm
Power Disel engine 22HP electric motor 15kw
Spindle
Spindle speed 64,128,287,557r/min
Spindle stroke 450mm
Hoist
Max.lifting speeed 2400kg
Single line lifting speed 0.41,0.82,1.64m/s
Wirerope caliber 13mm
Reel diameter 140mm
Hug floodgate caliber 260mm
Hug foldgate belt width 70mm
Mud pump
Displacement Diesel engine 170L/min electric motor 150L/min
Maximun pressure 3Mpa
Work pressure 1.5Mpa
Inlet pipe caliber 40mm
Outlet pipe caliber 30mm
Triangle conveyer belt B1728mm
Hydraulic oil pump
Type CBT-F-314
Triangle conveyer belt B1100*1
