Parameters:
Product type | Name | Four wheel electric concrete laser leveling machine | Unit |
Type | YZ25-4 | ||
Engine | Mode | HONDA GX690 | |
Type | petrol,Air cooled 4 stroke,Double cylinder | ||
Power | 25 | HP | |
Lubrication oil level | 1.9 | L | |
Fuel tank volume | 34 | L | |
Leveling system | Working mode of screed head | Stationary type | |
Screed width | 2500 | mm | |
Paving mode | Screw conveyor spreading | ||
Paving thickness | 60-300 | mm | |
Screw conveyor power | Low speed large torque cycloidal hydraulic motor | ||
Control mode of vibrating system | Vibration motor | ||
Excitation force | 2000 | N | |
Vibration frequency | 50 | Hz | |
Laser system | Control mode of laser system | Microcomputer laser scanning | |
Control effect of laser system | Flat surface,Slope,Double slope(three-dimensional) | ||
Driving system | Drive type | Reducer+Motor | |
Wheel | Solid puncture proof tyre | ||
Speed | 0-40 | m/min | |
Operation modes | Seat position | Rear-mounted | |
Forward, back away | Handle control,Stepless speed change | ||
Turning | Hydraulic power assisted,Steering wheel control | ||
Cleaning system | Power | External motor | |
Theoretical flow | 20 | L/min | |
Rated pressure | 7 | Mpa | |
Size and weight | Outline dimension | 3370*2890*1850 | mm |
Net weight | 800 | Kg |
