Product Application

Pile driving speed,the average 3 minutes can realize piling 6 meters deep,namely a hole 3 minutes to play.
Oil province,is a common driver uses around half of a year can be a driver left money for you.
Bit using manganese steel manufacturing,through processing,are suitable for all kinds of geological environment.
Crawler walking,high walking and climbing ability
The frame can be moved back and forth,bit can be adjusted,high piling position accuracy.

Technical  Parameter

1Diesel engine power65kw
2Walking motor torque (max)5700N.M
3Rotary motor max torque(impact drill)2000-2500N.M
4Rotary motor max torque(Auger drill)8000-10000N.M
5Pile height (max)4500mm
6Mast route3700mm
7Drill depth(impact drill)3500mm
8Drill diameters(impact drill)68-300mm
9Drill depth(auger drill)3500mm
10Drill diameters(auger drill)90-500mm
11Drill angle(L/R)25/-90 °
12Drill angle(forward/backward)20/-20 °
13Hydraulic system pressure16Mpa
14Hydraulic system flow90L/min
15Travelling speed1.6Km/h
16Chassis spec2500*2000*520mm
17Track chassis height300mm
18Track height above the ground230mm
19Clambing ability:≤ 30°
20Track working pressure13Mpa
21Track rotation angle360°
22Hydraulic hammer impact power6-8T
23Dimension(L*W*H)4000*2000*6000mm (Working)
24Dimension(L*W*H)6000*2000*2400mm (Folden)
25Net weight6000kgs
