Product Description
Technical Paramter
ItemsHW10-50QY
Total operating weight3100kg
Transportation dimension5500*1700*2650
Wheel base1350mm
Tread2050mm
Min Ground Clearance230mm
Loading bucket capacity0.5m3
Backhoe bucket capacity0.1-0.2m3
Digging up capacity25KN
Bucket discharge height2850mm
Backhoe bucket height1850mm
Max.Digging depth2100mm
Bucket slewing（swing）angle180oBoom
EngineSD490
Rated power/speed39kw,2400r/m
Max.travel speed27km/h
Wheel Tire size20.5-16diameter840width 320
Wheel pressure0.25Mpa
Steering angle35o
Working Pressure15MPa
Main Features
1.Low-speed and large torque Weichai engine meeting the requirement of China Ⅱ emission standard is provided, with low fuel consumption, strong power and high reliability.
2.Electricity-controlled shift transmission case of famous international brand is used, with four front gear positions and four rear gear positions and is easy and quick to operate. Internal famous brand of drive axle is configured and is provided with electrically-controlled differential lock with high traffic ability. Closed wet double brake is used, with large bearing capacity, high reliability and is more suitable for various bad operating conditions.
3. Load-sensing full hydraulic steering system is used, with light and quick steering and stable and reliable performances and is stable to operate. Hydraulic system with confluent and split logic functions is provided to realize compound action of excavation.
4. Reinforced excavating movable arm and bucket rod are used, with high reliability. Movable arm swing has damping buffer, which can ensure a stable and successful operation. It is optional to equip standard bucket rod or telescopic bucket rod to meet various demand of customer.
5.The integrated LVD is adopted, which ensures high human-machine interaction. The centralized control is adopted for the electric apparatus of entire machine, which ensures convenient inspection and maintenance and high reliability of electrical apparatus element.
6. The cab is provided with full height glazing all-round, wide visual field and standard air conditioning, which ensures a comfortable driving environment.
7.Many excavating or loading auxiliary appliances are provided to meet the various demand of user.
2.Electricity-controlled shift transmission case of famous international brand is used, with four front gear positions and four rear gear positions and is easy and quick to operate. Internal famous brand of drive axle is configured and is provided with electrically-controlled differential lock with high traffic ability. Closed wet double brake is used, with large bearing capacity, high reliability and is more suitable for various bad operating conditions.
3. Load-sensing full hydraulic steering system is used, with light and quick steering and stable and reliable performances and is stable to operate. Hydraulic system with confluent and split logic functions is provided to realize compound action of excavation.
4. Reinforced excavating movable arm and bucket rod are used, with high reliability. Movable arm swing has damping buffer, which can ensure a stable and successful operation. It is optional to equip standard bucket rod or telescopic bucket rod to meet various demand of customer.
5.The integrated LVD is adopted, which ensures high human-machine interaction. The centralized control is adopted for the electric apparatus of entire machine, which ensures convenient inspection and maintenance and high reliability of electrical apparatus element.
6. The cab is provided with full height glazing all-round, wide visual field and standard air conditioning, which ensures a comfortable driving environment.
7.Many excavating or loading auxiliary appliances are provided to meet the various demand of user.
