3-8m Working Width Electric Type Road Construction Concrete Roller Pavement Leveling Machine With Vibrators

Click on the image to view the original image

Product：	views：43-8m Working Width Electric Type Road Construction Concrete Roller Pavement Leveling Machine With Vibrators
Branch：	HWGK
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:26

Product Details

Overview

Quick Details

Production Capacity:: 5KM/Day

Power(W):: 12kw

Max. Paving Thickness:: 220-300mm

Condition:: New

Paving Width:: 3-8m

Place of Origin:: China

Brand Name:: HWGK

Model Number:: HWP-219

Dimension(L*W*H):: L*1820*1200mm

Weight:: 450-1500kgs

Certification:: ISO

Product name:: Concrete Roller Pavement Leveling Machine With Vibrators

Dia of Roller:: 219mm

Quantity of Roller:: 2 rollers and 1 auger

Roller Rotation Rate:: 36rpm

Vibrator Detail:: 50mm, 2m

Concrete Vibrator Distance:: 50cm

Material of Machine Body:: Iron

Voltage/Frequency:: 380V/50Hz

Vibrator paver machine Travel speed:: 0-5 m/min

Traveling Motor Power:: 3kw

Warranty:: 1 Year

After-sales Service Provided:: Engineers available to service machinery overseas

Supply Ability

Supply Ability:: 100 Set/Sets per Month Concrete Roller Pavement Leveling Machine With Vibrators

Packaging & Delivery

Packaging Details: Export Standard Packing

Port: All ports in China

Lead Time:: Within 3 Days

Product Description

HWP-219 Model Concrete Roller Pavement Leveling Machine With Vibrators is the most advanced machine used for all kinds pavement, road, square, airport to make the road smoothing. It is specially designed for road construction. It is a combination of the concrete roller paver and concrete vibrators. This unique design helps the machine to reduce large quantity needs of labors and highly improved the working efficiency.

Model	HWP-219
Working Width	3-8m
Max Insert Vibrator Depth	300mm
Travel Speed	0-5m/min
Dia of Roller	219mm
Quantity of Roller	2 rollers and 1 auger
Roller Rotation Rate	36rpm
Vibrator Detail	50mm, 2m
Concrete Vibrator Distance	50cm
Material of Machine Body	Iron
Voltage/Frequency	380V/50Hz
Vibrator Motor Power	1.5kw
Lifting Motor Power	1.5kw
Traveling Motor Power	3kw
Auger Motor Power	4kw
