Floor Price!! Mini Road Line Marking Machine For Parking Use

Click on the image to view the original image

Product：	views：3Floor Price!! Mini Road Line Marking Machine For Parking Use
Branch：	HWGK
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:27

Product Details

Overview

Quick Details

Power(W):: 4.3HP

Dimension(L*W*H):: 108*71*65cm

Weight:: 85kg

Condition:: New

Place of Origin:: China

Brand Name:: HWGK

Model Number:: HW-HX8

Features:: Cold Paint

Certification:: ISO

Name:: Cold Paint Road Line Marking Machine

Available Paint:: oil paint,emulsion paint,some anticorrosive paint

After-sales Service Provided:: Engineers available to service machinery overseas

Warranty:: 1 Year

Supply Ability

Supply Ability:: 2000 Set/Sets per Month Road Marking Machine

Packaging & Delivery

Packaging Details: Export Wooden Box

Port: Qingdao

Lead Time:: Shipped in 3 days after payment

Product Description

Main Features

1,Stable pressure
2,Large flow
3,Markings in appearance
4,Uniform thickness
5,Running light
6,Operation is simple and suitable for all types of marking places at room temperature.

Product Application

HW-HX8 Hand-push road marking machine uses special high precision cast iron marking shoe to ensure that the marking line comes to uniform side and thickness, linear appearance. The glass beads spread complete with automatic speed control buffer devices. The positioner upon back wheel make sure the machine go straight. This machine has the advantage of high quality construction, fast, flexible operation, conveninet maintance and so on. It can be suitable for highway, municipal roads, village or town road, guiding arrows, words, parking lines, factories, etc.

Technical Parameter

Model	HW-HX8
Marking width	10 ~ 450mm (adjustable)
Spraying thickness	0.2 ~ 0.4mm
Paint pump maximum flow	8L/min
Max output pressure	250Bar
Nozzle standard configuration	0.019"
Max. Nozzle Size	0.025"
High pressure pipe length	15m
Tank capacity	10L
