Ø Suitable for welding carbon steel, stainless steel, aluminum and aluminum alloy;
Ø Low cost, High welding rate, Simplify the working process;
Ø Specially designed main power supply, the whole welding process controlled by the microprocessor,current regulation and high performance ensure precise repeatability and optimum welding results;
Ø Stepless adjustment of weding current and welding time can be preset accurately and reliablely.
Model | RSR-1600 | RSR-2500 |
Size of Welding Bolt | M3-M8 | M3-M10 |
Input Voltage | AC220V | AC220V |
Input Frequency | 50/60Hz | 50/60Hz |
Power way | capacitance store | capacitance store |
Charging voltage | 10-180 V | 10-180 V |
Full Charging time | 3.5s | 4s |
Welding efficiency | 10-20 pcs/min | 10-20 pcs/min |
Welding time | 1-5ms | 1-3ms |
Capacitance Capacity | 66000uF | 99000uF |
Welding ability | 1600W | 2500W |
IP Grade | IP21S | IP21S |
Neight Weight | 18KG | 20KG |
Gross Weight | 25KG | 25KG |
Machine Size | 475*230*410mm | 475*230*410mm |
Packing Size | 600*336*470mm | 600*336*470mm |
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment <=10000USD, 100% in advance. Payment >=10000USD, 50% T/T in advance ,balance before shippment.
