ND-550 Universal Portable Railway Spanner Wrench/Rail Impact Wrench With Low Price
Click on the image to view the original image
Product： views：3ND-550 Universal Portable Railway Spanner Wrench/Rail Impact Wrench With Low Price
Branch： HWGK
Type： Torque Wrench
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 20:28
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
China
Brand Name:
HWGK
Model Number:
ND-550
Type:
Torque Wrench
Material:
Stainless Steel
Size:
650 * 280 * 380mm
Product name:
Railway Internal Combustion Mechanical Wrench
Engine Type:
two stroke, forcing, cold wind, single cylinder
Power:
1.47 kw
Displacement:
51.7 cc
Fuel Tank Capacity:
1L
Fuel Mixture Ratio:
25 : 1
Revolution (Idle):
2700 RPM + 250
Fastening Torque Range:
550-1700 N.m (406-1250 ft LBS.)
Net Weight:
18 KGS (39.60 LBS)
Maximum Torque:
0.34 kg - m / 550 RPM
Supply Ability
Supply Ability:
3000 Set/Sets per Month Internal Combustion Wrench
Packaging & Delivery
Packaging Details
Export Standard Box
Port
Qingdao Port
Lead Time:
Within 3Days
Product Description

It can loosen or fasten M22,M24 nut effectively to satisfy the railway technical requirement.It is small in size,light in weight,simple and quick in operation.It"s realy an ideal special tool suitable for loosening and fastening sleeper nut,and it can also reduce labor intensity.

Engine Type
two stroke, force, the cold wind, single cylinder
Power
1.47 kw
Displacement
51.7 cc, Φ 44 × 34 mm
Fuel Tank Capacity
1L
Fuel Mixture Ratio
25 : 1
Revolution (Idle)
2700 RPM + 250
Revolution (Load)
7120 RPM
Revolution (Maximum)
9880 RPM
Maximum Output
2.03 Ps / 6500 RPM
Maximum Torque
0.34 kg - m / 550 RPM
Compression Rate
7.4:1
Specific Fuel Consumption
380 g/Ps. H
Carburetor Type
diaphragm
Fastening Torque Range
550-1700 N.m (406-1250 ft LBS.)
Clutch Speed
1200 RPM
Net Weight
18 KGS (39.60 LBS)
The Overall Size
650 x 280 x 380 mm
Detailed Images
Certificates
Shipment
FAQ


Q: Are you trading company or manufacturer ?
A: We are factory.


Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.


Q: What is your terms of payment ?
A: Payment <=10000USD, 100% in advance. Payment >=10000USD, 50% T/T in advance ,balance before shippment.
