new designed high power Metal Cutting Hacksaw Machine

Click on the image to view the original image

Product：	views：3new designed high power Metal Cutting Hacksaw Machine
Branch：	HENG WANG
Type：	Semi Automatic
Size：	30X20X30 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:29

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: HENG WANG

After-sales Service Provided:: Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service, No after-sales service, No overseas service provided

Warranty:: 1 Year

Name:: 2016 newdesignedhigh powerMetal Cutting Hacksaw Machine

Application:: Steel

Type:: Semi Automatic

Usage:: Industrial Profiles

Certification:: ISO9001

Power:: 3.22KW

Weight:: 1200kg

Function:: Angle Iron Cutting

Product name:: high efficiency Metal Cutting Hacksaw Machine

Packaging & Delivery

Selling Units:: Single item

Single package size:: 30X20X30 cm

Single gross weight:: 65.0 kg

Package Type:: wooden caseor as your requirement

Lead Time:

Quantity(Set)	1 - 1	>1
Est. Time(days)	3	To be negotiated

Product Description

2016 new designed high power Metal Cutting Hacksaw Machine

Features:

1.Automatic cutting process
2.With clamping feeding device
3.With safety protection device
4. It has different speeds and wide cutting scope.
5. Hydrauic transmission, simple running, easy upkeep.

Specification:

Model		G7125	G7132	G7140	G7150
Cutting capacity	Round bar	250mm	320mm	400mm	500mm
	Square bar	220x220mm	290x290mm	330x330mm	400x400mm
	Oblique saw	45°	45°	45°	45°
Sawing speed		43,50,60,86, 100,120	34,60,84	34,60,84	34,60,84
Blade size		450x45 x2.25mm	600x50 x2.5mm	650x55 x2.5mm	750x63 x2.5mm
Main motor		3.22kw	3.44kw	4.34kw	4.34kw
Coolant pump motor		0.04kw 2step	0.04kw 2step	0.04kw 2step	0.09kw 2step
Saw blade rapid down		0.25kw 4step	0.25kw 4step	0.25kw 4step	0.25kw 4step
Packing size		2000x950 x1300mm	2440x1020 x1600mm	2440x1020 x1600mm	2440x1190 x1760mm
N.W./G.W.		600/830kg	1100/1350kg	1200/1450kg	1450/1700kg
