high efficiency hand held air hammer pneumatic stone rock breaking tools

Click on the image to view the original image

Product：	views：3high efficiency hand held air hammer pneumatic stone rock breaking tools
Branch：	HENGWANG
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:29

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: HENGWANG

Model Number:: B47,B50,B67,B87,B90

Hammer Type:: Breaker Hammer

Dimensions:: 520*540*680mm

Frequency:: 50Hz/60Hz

Max. Drilling Diameter:: 30mm

No-Load Speed:: 2040r/min

Rated Input Power:: 1500W

Rated Voltage:: 220V

Weight:: 20KG, 20KG

Name:: hand held air hammerpneumatic stonerock breaking tools

Color:: Customized

Warranty:: One Year

Input Power:: 850W/1300W

Dimension:: 25*08 mm

MOQ:: 1pc

Certificate:: ISO9001

Function:: Demolitio Breaker

Application:: Construction

Supply Ability

Supply Ability:: 1000 Piece/Pieces per Month high efficiency hand held air hammerpneumatic stonerock br

Packaging & Delivery

Packaging Details: wooden caseor as your requirement

Port: SHANGHAIQINGDAO DALIAN SHENZHEN MINGBO

Lead Time:: within 3 days after receive your payment

high efficiency hand held air hammer pneumatic stone rock breaking tools

Product Description

Crusher powered by compressed air tools with high efficiency, high reliability, small recoil, durable, etc. Can complete the ferroconcrete, rocks and efficient asphalt the broken pieces of work, suitable for Bridges, roads, buildings, electric power, the tap water pipe network construction work of maintenance, repair and dismantling

Technical Parameter

Model	B47	B50	B67	B87	B90
length	550mm	660mm	615 mm	686 mm	745mm
weight	21.5kg	18kg	30 kg	39 kg	34Kg
Air pressure	0.63mpa	0.63mpa	0.63mpa	0.63 Mpa	0.63 Mpa
impacting frequency	21.6hz	22 hz	24 hz	18 hz	16HZ
gas consumption	23l/s	33 l/s	42 l/s	55 l/s	27L/s
Bit Head Size	25×108 mm	25×108 mm	25×108 mm	32×152mm	32×152mm
