Home > Products > YZC3 3T Hydraulic vibration Double Drum Vibratory Roller

YZC3 3T Hydraulic vibration Double Drum Vibratory Roller

Click on the image to view the original image

Product：	views：1YZC3 3T Hydraulic vibration Double Drum Vibratory Roller
Branch：	Hengwang
Type：	Double Drum Roller
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:31

Product Details

Overview

Quick Details

Power(W):: 21kw

Travel Speed:: 0-5KM/h

Static Linear Pressure:: 162N/cm

Condition:: New

Type:: Double Drum Roller

Grade Ability:: 20%

Place of Origin:: Shandong, China

Brand Name:: Hengwang

Model Number:: YZC3

Dimension(L*W*H):: 2990*1280*2360mm

Weight:: 12000kg

Certification:: ISO

Name:: YZC3 3T Hydraulic vibrationDouble Drum Vibratory Roller

Vibration frequency:: 50Hz

Engine Model:: N385Q

Starting mode:: Electric

Vibration control:: Hydraulic Vibration

Drum width:: 1000mm

Color:: Customer's Demands

Warranty:: 2 Year

Exciting force:: 35KN

Engine type:: diesel engine

After-sales Service Provided:: Overseas service center available

Supply Ability

Supply Ability:: 1000 Piece/Pieces per Month YZC3 3T Hydraulic vibration Double Drum Vibratory Roller

Packaging & Delivery

Packaging Details: wooden case or as your requirement

Port: SHANGHAI QINGDAO SHENZHEN DALIAN

Lead Time:: Shipped in 3 days after payment

YZC3 3T Hydraulic vibration Double Drum Vibratory Roller

Product Description

Application:

City road, Inter-city and township road, Stadium and other projects etc.. This roller is suitable for compacting and repairing the asphalt pavement and general road base.

Main Features

Mechanical drive, two-speed gear shift. Hydraulic vibration, Hydraulic steering and easy to operate.

Articulated frame with flexible steering. Compact design and nice appearance.

Equipped with gravity nature sprinkler system, or the electric control pressurized sprinkling system is optional.

A trailer is provided for transportation

Compacting force up to 6t

Scraper and sprinkling devices on all drums

Technical Data

Operating weight	3000	kg	Theoretical amplitude of vibration	0.58	mm
Diameter of vibrating drum	800	mm	Moving speed gear 1	2	km/h
Rolling width	1000	mm	Moving speed gear 2	5.6	km/h
Static Linear Pressure	162	N/cm	Grade ability	20%
Activating force	35	KN	Diesel engine model Rated rotation speed Rated power	N385Q 2400 21	r/min kw
Vibration frequency	50	Hz	overall dimensions LWH	2990×1280×2360	mm
