Max 6.5m Piling Depth Screw Ground Machine/Solar Farm Hydraulic Pile Driver For Pv Installation

Click on the image to view the original image

Product：	views：5Max 6.5m Piling Depth Screw Ground Machine/Solar Farm Hydraulic Pile Driver For Pv Installation
Branch：	HWGK
Size：	90X40X70 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:31

Product Details

Overview

Quick Details

Piling Speed(m/min):: 1-2m/min

Efficiency:: High Efficiency

After-sales Service Provided:: Video technical support, Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service

Warranty:: 1 Year

Applicable Industries:: Construction works

Condition:: New

Place of Origin:: Shandong, China

Brand Name:: HWGK

Weight:: 6-8T

Dimension(L*W*H):: 7200*2100*4300 mm

Certification:: ISO9001

UNIQUE SELLING POINT:: Long lifetime

Product Name:: Hydraulic Pressure Pile Driver

Multi functions:: Drilling, Pressing,Pulling Piles

Pile height (max):: 6.5m

Rotary:: 360°

Pile type:: Hammer/pile/screw

COLOR:: Blue

Advantages:: Adapt to complex terrain/High efficiency

Packaging & Delivery

Selling Units:: Single item

Single package size:: 90X40X70 cm

Single gross weight:: 68.0 kg

Package Type:: 20'FCL 1 SET. 40'FCL 2 SET

Lead Time:

Quantity(Set)	1 - 6	>6
Est. Time(days)	14	To be negotiated

Product Description

The hydraulic pile driver is a kind of multifunctional highway guardrail pile construction machinery, with different configuration it can accomplish many functions, such as piling, pile extracting, and drilling on the stable layer of road before piling.

Advantages:

1 Systems are simple; while individual units are robust, repairs to nearly any component can be made by any mechanic.

2 Parts for repairs are readily available.

3 Interchangeablity of parts is supported by all models.

4 Similarities to other machines currently in use by customers ensure that further training in the usage of these tools is unnecessary.

5 Supplying power and fuel to these system is very feasible at construction sites.

Technical Parameter

SPECIFICATIONS FOR HAMMER PILE DRIVER
Pile driver part	Engine power	Kw	34
	No. of cylinders	PCS	4
	Engine brand		Changcai engine
	Working pressure	MPA	16-20
	Working flow	L/Min	120
	Wheel distance	M	2
	Machine size	mm	4100×2000×2200
	Machine weight	T	3.5
Track shoe part	Working pressure	MPA	20
	Rubber track weight	T	5
	Total displacement	1860
	Total bearing weight	KGS	5000
	Walking speed	kw/h	0-3
	Ground connection beta ratio		0.036
	Pulling capacity	KGS	4300
	Clambing ability		≤ 30
Hydraulic hammer Part	Drill rod diameters	mm	70
	Drill rod weight	KGS	19
	Hydraulic hammer weight	KGS	230
	Working flow	L/Min	40-70
	Working pressure	bar	110-140
	Impacting frequency	bpm	500-900

Detailed Images

Machine Parts

Name: Hydraulic Press Pile Driver
Brand: HWGK
Original: China
Domestic famous engines, strong driving force, low fuel consumption, high economic.

Main Parts

Name: Square hydraulic hammer
Brand: HWGK
Original: China
this hammer used for pressing the pile,pull out the pile,rotate the pile.

Machine Parts

Name: Round hydraulic hammer
Brand: HWGK
Original: China
Function 1: this hammer can drill the hard rock with air compressor.
Function 2: this hammer can drill the soil with the screw pipe.

Main Features

Name: Multifunction pile driver
Brand: HWGK
Original: China

this is the multifunction pile driver,we can change the different hammer to do the different works.it can press the pile,can drill the soil,also can drill the rock.

Oversea Service

In August of 2016 ,according to Mongolia customer"s request,our company sent technicist to Ulaanbaatar,Mongolia to offer the Oversea Service. With our help the progress of the works completed quickly and smoothly,final be highly appreciated by our customer.
