FRP-219 Model Concrete Road Paving Leveling Machine/Paver Roller For Sale

Click on the image to view the original image

Product：	views：3FRP-219 Model Concrete Road Paving Leveling Machine/Paver Roller For Sale
Branch：	Jining Hengwang
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:31

Product Details

Overview

Quick Details

Production Capacity:: Customized

Power(W):: 5.5-11kw

Max. Paving Thickness:: 300mm

Condition:: New

Paving Width:: 3-8m

Place of Origin:: China

Brand Name:: Jining Hengwang

Model Number:: FRP-219

Dimension(L*W*H):: L*1500*700mm

Weight:: 1600KG

Certification:: ISO9001

Name:: Concrete Pavement Paving Leveling Machine

Walking Speed:: 8-10m/min

Diameter of roller:: Diameter of 219 mm

Exciting frequency:: 32Hz

Exciting force:: 5.52KN

Warranty:: 12 Months

After-sales Service Provided:: Engineers available to service machinery overseas

Supply Ability

Supply Ability:: 600 Set/Sets per Month Paving Leveling Machine

Packaging & Delivery

Packaging Details: Export Standard Packing

Port: Qingdao

Lead Time:: Shipped in 7 days after payment

Product Description

Concrete paver leveling machine is very suitable for concrete pavement, concrete surface layer of the tunnel, bridges and paving construction. The largest advantage is to resolve general paver leveling machine working problems in restricted construction sites. Since its rollers can be easily changed and easy to transport.

Advantage:

1. Extensive use and users reflect well.
2. Widely used in the narrow road construction work which is restricted by environment.
3. Electric switch control is used, the operation is simple and it can walk straight.
4. This machine is designed for narrow cement road in mountains and village, gradeability is strong.

5. It can speed up the working efficiency to reduce the working cycle

Technical Parameter

Model	FRP-219
Paving width	≥3m
Paving thickness	300mm
Walking speed	8-10m/min
Diameter of roller	Φ219 mm
Exciting frequency	32Hz
Exciting force	5.52KN
Weight	1600kg
Size	L1500700mm

Model	FRP-219A
Paving width	3-8m
Electric Motor Power	3-7.5kw
Diesel Engine Power	30HP
Electric Generator Power	24kw
Paving thickness	200-300mm
Walking speed	9-12m/min
Diameter of roller	Φ219 mm
Size	L18001000mm
