Home > Products > Road pavement crack router grooving machine

Road pavement crack router grooving machine

Click on the image to view the original image

Product：	views：2Road pavement crack router grooving machine
Branch：	HW
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:33

Product Details

Overview

Quick Details

Working Width:: 30-50(mm)

Power(W):: 6600

Condition:: New

Working Depth:: 160-185MM

Place of Origin:: Shandong, China

Brand Name:: HW

Model Number:: HW

Voltage:: 220/380V

Dimension(L*W*H):: 930*565*1020mm

Weight:: 130kg

Certification:: CE ISO

Rotary Speed:: 1-2m/min

Diameter of Blade:: 350/400/450/500mm

Power Source:: Gasoline Engine

Running Speed:: 1-2m/min

Colour:: Yellow/Red

Disc Diameter(mm):: 350/400/450

Depth Adjustment:: Handle Rotation

Max Cutting Depth(mm):: 185

Water Tank Capacity(L):: 35

Packing Size(mm)(L*W*H):: 930*565*1020

After-sales Service Provided:: No overseas service provided

Warranty:: 1 Year

Supply Ability

Supply Ability:: 1000 Set/Sets per Week Road Grooving Machine

Packaging & Delivery

Packaging Details: wooden case

Port: Qingdao

Lead Time:: Within 3 days

Road pavement crack router grooving machine

Optional Spare Parts Of Asphalt Concrete Cutting Machine

1.Double water pipe---better cooling both side of blade

2.Rustless/ABS water tank---providing an optimum flow and volume of water for the blade

3.Super-rigid box frame---ensuring straight auts while resisting warping and vibration

4.Hinged front,lift-up blade guard--- to conveniently replace the diamond blade

5.Adjustable height handle---to esaily raise or lower cutting depth

Advantages Of Asphalt Concrete Cutting Machine

Technical Specification of Asphalt Concrete Cutting Machine:

Model	ROCC-450
Disc Diameter(mm)	350/400/450
Driving	Manual Push
Depth Adjustment	Handle Rotation
Max Cutting Depth(mm)	185
Water Tank Capacity(L)	35
Weight(Kgs)	128
Packing Size(mm)(LWH)	9305651020
