Home > Products > Backpack portable drilling and soil sampling product diamond core drilling products

Backpack portable drilling and soil sampling product diamond core drilling products

Click on the image to view the original image

Product：	views：2Backpack portable drilling and soil sampling product diamond core drilling products
Branch：	HWGK2100
Type：	Core Drilling Rig
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:33

Product Details

Overview

Quick Details

Condition:: New

Type:: Core Drilling Rig

Power Type:: Gasoline

Place of Origin:: Shandong, China

Brand Name:: HWGK2100

Model Number:: HW

Usage:: Coal

Voltage:: 380/220V

Power(W):: 5800

Dimension(L*W*H):: 30.48*28.02*30.48cm(engine)

Weight:: 25KGS

Certification:: ISO/CE

Application:: mineral,oil and gas exploration

rock core drilling diameter:: nomore than 10cm

Product name:: portable drilling equipment

Water consumption:: 14.4L/hr

Oil consumption:: 0.3L / min

Color:: Customised

Drilling rig power:: 7.75HP

Maximum drilling depth:: 30m

Gasoline engine:: KOHLER engine

Rated Power:: 5.8kw

Warranty:: 3 Year

After-sales Service Provided:: Overseas third-party support available

Supply Ability

Supply Ability:: 2500 Set/Sets per Month Backpack portable drilling and soil sampling product diamond cor

Packaging & Delivery

Packaging Details: regular packaging

Port: qingdao/dalian/ningbo/tianjing

Lead Time:

Quantity(Sets)	1 - 1	>1
Est. Time(days)	7	To be negotiated

Backpack portable drilling and soil sampling product diamond core drilling products

Product Description

1.The portable drilling machine is designed for mineral,oil and gas exploration, it is tailored for geological research and prospectors

2.we have decades of experience and accumulation in dozens of countries and regions in the world of field validation, we constantly improve and upgrade the quality of our products and we believe that the equipment will be helpful for your work

3. The engine of portable drilling machine is original Honda engine which has one of the best quality and long life service

Product parameter

Drilling diameter : 32-108mm

Drilling depth : 30m

Adaptation Geological :soil, loose cover, all kinds of rock

Consumption:about 0.3L / min

Drill diameter :φ32mm

Drill length :750mm (with joints)

Drill pipe material:titanium

Drill pipe weight: about 1.1kg

Gasoline brand :KOHLER

Gasoline models :XT Series 775

Gasoline engine power :7.75HP

Rated speed:2800rpm

Machine weight:about 25kg

Drilling work efficiency for Different rock stratum

Silicalite 69mm/min

Slate 119mm/min

Basalt 127mm/min

Sandstone 130mm/min

Dolomite 226mm/min

Limestone 241mm/min

Product Photos
