Home > Products > HW Model for core drilling machine with input power 1500W/electric core drill machine
HW Model for core drilling machine with input power 1500W/electric core drill machine
Click on the image to view the original image
Product： views：2HW Model for core drilling machine with input power 1500W/electric core drill machine
Branch： HW
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 20:34
  Negotiated
Product Details
Overview
Quick Details
Condition:
New
CNC or Not:
Normal
Drilling Speed:
200 - 1000r/min
Place of Origin:
Shandong, China
Brand Name:
HW
Model Number:
HWGK
Voltage:
110V/220V/240V
Power(W):
5.5HP
Dimension(L*W*H):
650x160x1000mm
Certification:
ISO9001: 2000CE
Frequency:
50-60Hz
Rated Input Power:
3200W
Name:
core drilling machine
Drill Type:
core drill
Rated Torque:
18N.M
Application:
reinforced concrete,brick,stone, Pavement Core Drilling Machine
No-Load Speed:
0-700r/min
Color:
According to order
Weight:
25kgs
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
10000 Set/Sets per Week core drilling machineon sale
Packaging & Delivery
Packaging Details
Regular packaging
Port
qingdao dalian ningbo shanghai
Lead Time:
with 3 days

High power Concrete diamond core drilling machine  with best price on sale

   core drilling machine

Product Description

     core drilling machine

 Product  Advantages



1. The new design of copper tube sealing efficiently prtect the motor and reduce   maintenance cost


2. Equipped with a safety clutch to protect the gear.


3. Equipped with a current overload protection switch to protect the motor.

     core drilling machine

 Product parameter

     core drilling machine

Product ModelHW-18/2EBMHW-18/2EBMIHW-26/3EBMHW-26/3EBMI
Brick Drilling Range5"
132mm		5"
132mm		6.5"
165mm		6.5"
165mm
Concrete Drilling Range3"
80mm		4"
110mm		4"
102mm		5"
130mm
Rated Voltage(V)110/220110/220110/220110/220
Rated Frequency(HZ)50-6050-6050-6050-60
Rated Input Power(W)1900190023002300
No-load Speed(RPM)700-1200
1050-1750		700-1200
1050-1750		400-850
750/1650
1200/2650		400-850
750/1650
1200/2650

     core drilling machine



Product Photos



 core drilling machine





Packaging & Shipping







Certifications



Customer Visit
