Crawler mounted hydraulic down the hole gold mining drilling rig
Click on the image to view the original image
Product： views：2Crawler mounted hydraulic down the hole gold mining drilling rig
Branch： HW Down-the-hole Drill
Type： Core Drilling Rig
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 20:35
  Negotiated
Product Details
Overview
Quick Details
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Place of Origin:
Shandong, China
Brand Name:
HW Down-the-hole Drill
Model Number:
HW hydraulic drilling machine
Usage:
Water Well
Voltage:
380V
Power(W):
37KW
Dimension(L*W*H):
4*2.2*2.6
Weight:
4000KG
Certification:
ISO9001
Warranty:
1year hydraulic drilling machine, 1Years
Model:
Hot sale water well drilling machine water drilling
drilling work:
water well. mining
depth:
600m
diesel engine power:
50HP-102hp
Technical guidance: long time:
Technical guidance: long time
Down-the-hole Drill:
Down-the-hole Drill
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month drilling rig
Packaging & Delivery
Packaging Details
export standard package
Down-the-hole Drill
Port
QINGDAOSHANGHAI TIANIN
Lead Time:
15 work days Down-the-hole Drill

Crawler mounted hydraulic down the hole gold mining drilling rig            :

Product Description



Drilling depth

m

100

250

300

600

Drilling  DI

mm

300

200

150

75

Open hole DI

mm

300

End hole  DI

mm

75

Drilling rod

mm

Φ60

Drilling angle



90°-65°

Rotary Spindle

Spindle forward speed

r/min

30-1050

Spindle reverse speed

r/min

29-137

Spindle stroke

mm

560

Spindle inner diameter

mm

96

Spindle lifting capacity

KN

60

Main Winch  ( drive hydraulic system)

Single line lifting speed

m/min

0-45

Hug floodgate belt width

mm

90

Tightrope diameter

mm

14

Hoist single line lifting capacity

KN

40

Roller diameter

mm

200

Roller cubic measure

m

30

Gear Oil pump

Duplex gear oil pump           CBF-F63/25

Front displacement,pressure



63mL/r    20Mpa

Behind displacement,pressure



 25mL/r    20Mpa

Drilling rig Power

Diesel engine

Hp

   R4105ZD    50HP

Electric motor

KW

   Y180L-4      37KW































































Figure photos for rock drilling



 Qualification & certification for rock drilling

History order

Welcome to visit our factory
