LED rechargeable underground mining helmet cap light

Click on the image to view the original image

Product：	views：3LED rechargeable underground mining helmet cap light
Branch：	HWGK
Type：	Headlamps
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:35

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: HWGK

Model Number:: KL5LM(C)

Usage:: Mining, tunnel engineering, electric power communication at night

Power Source:: mining light is rechargeable battery

Lighting Period (h):: >12

Battery Type:: Lithium Ion

Certification:: CCC, GS

IP Rating:: IP54

Lamp Body Material:: Bakelite

Light Source:: LED

voltage:: 3.3V

Product name:: mining light

Color:: yellow or red

Type:: Headlamps

Warranty(Year):: 1

Lamp Power(W):: 1300

LED Light Source:: Led Bulbs

Supply Ability

Supply Ability:: 1000 Set/Sets per Week mining light

Packaging & Delivery

Packaging Details: mining lights are packed in wooden box or according to your requirements

Port: QINGDAO

Lead Time:: Within 7days after receiving payments

LED coal mining cap light lamp

Feature and Appliance:

1. Mining light is portable, the lamp head and battery part are connected by cable"s upper

cover to be a whole miner"s lamp. Lamp head could be fixed on cap lamp.

2. A LED main light source is installed in, KL4LM(A) or KL5LM(A) several LED auxiliary light

sources.Clockwise turn on switch, main source and auxiliary sources illuminate alternatively.

3. This battery case is designed with closed wear-ring, convenient for carrying.

4. This lamp head is designed with charging device, matching with charging set, convenient

and reliable for charging.

5. PTC self-protection is set between battery group, and reusable short circuit protective

device is set on cable"s battery end. Thus, this is very safe and reliable.

Main specification:

No	Item		Unit	Data
1	Rated capacity		Ah	5
2	Nominal voltage		V	3.7
3	Lighting time		h	20
4	LEDlight source	Rated voltage	V	4.2
		Main light source/power	mA	300
		Auxiliary light source	mA	120
5	Max illuminance at 1m	Begin lighting	Lx	10000
5	Max illuminance at 1m	Lighting 11h	Lx	8000
6	Weight		g	490
7	Nos of battery cycle		times	800
8	Carton packing		roll/CNT	20
9	Packing size		cm	363644
