KHYD150 Electric Rock Drill Machine ,Electric Rock Drill Machine For Hard Rock Or Earth Drilling

Click on the image to view the original image

Product：	views：3KHYD150 Electric Rock Drill Machine ,Electric Rock Drill Machine For Hard Rock Or Earth Drilling
Branch：	HENGWANG
Type：	Rotary Drilling Rig
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:36

Product Details

Overview

Quick Details

Condition:: New

Type:: Rotary Drilling Rig

Power Type:: Electric

Place of Origin:: Shandong, China

Brand Name:: HENGWANG

Usage:: MINING

Voltage:: 380v

Power(W):: 7.5KW

Dimension(L*W*H):: 180*70*80CM

Weight:: 150kg

Certification:: ISO

Warranty:: 1YEAR

Product name:: Electric Rock Drill Machine For Hard Rock Or Earth Drilling

Application:: Multifunction

Drilling depth:: 25m

Drilling diameter:: 80-120mm

Spindle Speed:: 1440r/min

Drilling method:: Rotating

Model:: KHYD150

Color:: asyour r equirement

Key words:: Electric Rock Drill Machine

Feature:: High Drilling Efficiency

After-sales Service Provided:: Engineers available to service machinery overseas

Packaging & Delivery

Selling Units:: Single item

Single volume:: 1 cm³

Single gross weight:: 150.0 kg

Lead Time:

Quantity(Set)	1 - 10	>10
Est. Time(days)	7	To be negotiated

Product Description

Main Characteristics
1.Electric rock drill is used for drilling burst mine hole in rock.

2. It is widely used in the mine shaft excavation, road construction, water conservancy construction, metallurgy mining, rock engineering, quarry operation, basic engineering drilling reinforcement construction process.

3.The explosion-proof electric rock drill is used for drilling water injection hole, on coal seam, exploring water holes and discharging gas, also can be used for soft rock tunnel excavation.

4.Above mentioned models can do wet type and dry type work (equipped with twist drill rod). Drills holes horizontally forward or tilt up, only need to control the handwheel, the drill will track forward and backward automatically on the railway.

Item	Rock diameter mm	Diameter of coal seam mm	Depth of rock m	Depth of coal seam m	Speed r/min	power kw	weight kg
KHYD40	42	45-60	5	20-60	2814	2	40
KHYD75	42	45-80	10	30-80	1420	3	75
KHYD140	42-80	80-100	20	30-80	1440	5.5	140
KHYD150	42-80	80-120	25	40-100	1440	7.5	150
