Main Features
1, the use of a wide range of simple structure, smooth transmission, operation effort, easy to achieve automatic control.
2, for swamps, floods, deserts, paddy fields, tropical rain forests, snow and ice and other complex road conditions.
3, single-cylinder power system, low fuel consumption.
4, traction, climbing performance is good, strong transport capacity.
5, turning radius is small, flexible, especially to adapt to narrow space, reducing the cost of building roads.
6, with electrical start, handle centralized, easy to operate.
7, with a hydraulic landing, dumping, reduce labor intensity, improve transport efficiency.
Specification
Machine weight: 1.4 tons
Maximum load: 2 tons
Truck crane maximum lifting: 1 ton
Boom lifting height: 3 meters
Stalls and speed: +3 forward speed +3 reverse gear reverse the fastest 8 km slowest 0.6 km
Cabin size: 1.6 meters * 2.0 meters (can be customized)
Climbing ability: 28 degrees
Engine power: 28 hp
Overcrowding capacity: 30 cm
Vehicle length * width * height (cm): 340cm * 160cm * 120cm
Chassis length * width * height (cm): 195cm * 160cm * 45cm
Diesel Engine Model: WL-28
Diesel power (kw / r / min): 20.24Kw / 2200r / min
The lowest point of the car from the ground height (cm): 25cm
Cargo Length * Width * Height (cm): 180cm * 160cm * 40cm (can be customized)
Maximum flat road load (kg): 2000kg
Maximum slope load (kg): 1200kg
Driving speed: the slowest: 1.2km / h fastest: 6km / h
Obstacle obstacle: 20 degrees maximum slope, vertical height of 20cm obstacles
Wade depth: 40cm
Depth of mud: 20cm
Track ground length (cm): 130cm
Track Type: 400mm
Can be modified according to the requirements of the container, the installation of lifting luggage, dump, lorry and so on
