construction machine road roller ,500kg road roller compactor price

Click on the image to view the original image

Product：	views：3construction machine road roller ,500kg road roller compactor price
Branch：	heng wang
Type：	Single Drum Roller
Size：	116X90X110 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:36

Product Details

Overview

Quick Details

Power(W):: 4.5KW

Travel Speed:: 0-4km/h

Static Linear Pressure:: 147N/cm

Condition:: New

Type:: Single Drum Roller

Grade Ability:: 30%

Place of Origin:: Shandong, China

Brand Name:: heng wang

Dimension(L*W*H):: 1160x900x1100mm

Weight:: 530KG

Certification:: ISO

Product name:: construction machine road roller ,500kg road roller compactor price

Name:: construction machine road roller ,500kg road roller compactor price

Vibration frequency:: 75HZ

Engine Model:: CF178F

Starting mode:: Electric

Engine type:: CF178F

Exciting force:: 20 KN

Keywords:: Single Drum Vibration Roller

DRUM WIDTH:: 600mm

Water tank:: 30L

After-sales Service Provided:: Engineers available to service machinery overseas

Packaging & Delivery

Selling Units:: Single item

Single package size:: 116X90X110 cm

Single gross weight:: 530.0 kg

Package Type:: wooden case

Lead Time:

Quantity(Set)	1 - 10	>10
Est. Time(days)	7	To be negotiated

Product Description

Walking type single roller are widely used in the compaction of asphalt surface, compaction gravel, sand and other projects.The characteristics of superior performance, easy operation, durable

Features

The basic configuration;
Domestic brands often diesel engine, powerful, easy to start.
International brand NSK precision arrange ushering centripetal ball bearings, to ensure the overall performance in good condition.
Two-way hydraulic walking, homework radius is small, the operation is simple, flexible rotation.
Surface coating processing, beautiful and easy, rust corrosion.

Specification

model	HW-YL600C	model	HW-YL600C
walking		type	( Diesel engine, air cooling 4 stroke)
speed	0-4km/h	power	4.0hp/3600rpm
Steering radius	30%	fuel tank capacity	2.5L
compaction		Fuel consumption	280g/kwh
Nominal amplitude	0.5mm	dimensions
vibration frequency	75Hz	Width of the steel wheel	600mm
Vibration force	20kN	Steel wheel diameter	450mm
water tank capacity	20L	length about armrest flat	1650mm
work		width	800mm
drive	Hydraulic pump and motor	height about Arm stand	1300mm
vibration	Mechanical transmission - electromagnetic clutch	Packing size	1160x900x1100mm
engine		weight
model	CF170	Work weight	350kg

model	HW-YL700	model	HW-YL700
walking		type	diesel engine, air cooling 4 stroke
speed	0-4km/h	power	6.0hp/3600rpm
Steering radius	30%	fuel tank capacity	3.5L
compaction		Fuel consumption	280g/kwh
Nominal amplitude	0.5mm	dimensions
vibration frequency	75Hz	Width of the steel wheel	700mm
Vibration force	20kN	Steel wheel diameter	530mm
water tank capacity	20L	length about armrest flat	1900mm
work		width	860mm
drive	Hydraulic pump and motor	height about Arm stand	1400mm
vibration	Mechanical transmission - electromagnetic clutch	Packing size	1160x900x1100mm
engine		weight
model	CF178F	Work weight	520kg
