Product Application
Apply for engineering hole such as drilling blasting hole, guardrail hole in mines, quarries, expressway, the mountain barrier reinforcement, anchorage, geothermal air conditioning hole.
DTH hammer working principle:
At the beginning of the impact stroke, the piston and the valve plate are in the upper position, and the compressed air enters the upper chamber of the cylinder through the radial holes of the valve cover and the valve seat, and pushes the piston to move downward at high speed to impact the drill bit. When the piston row to the spline groove of the bushing is closed, the pressure in the lower chamber begins to rise, so that the center hole of the upper end of the piston leaves the gas distribution rod, the upper chamber passes through the atmosphere, the pressure is lowered, and the working stroke ends. When the piston hits the tail of the drill bit, the valve piece is reversed due to the upper and lower pressure difference, and the piston repeats the return stroke motion.
Main Features
1. The single impact energy is large, and the energy consumption of the broken rock is low;
2. The weight ratio of the piston to the drill bit is close, and the effective action time is long, which is beneficial to improve the rock crushing efficiency and extend the life of the drill;
3. The center exhaust slag discharge effect is good, reducing the repeated crushing of the rock;
4. The impactor has a check valve device. The blasthole can be drilled in the water. HR series down-the-hole impactor. Widely used in thousands of energy, transportation, metallurgy, building materials and other industries, is an ideal perforation equipment.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
