Product model | HW16B |
Total mass kg | 16335 |
Overall dimension mm | 11620mm*2440mm*3550mm |
Rated elevating capacity kg | 16000 |
Max Lifting Moment KN.M | 480 |
Max. Lifting Height m | 33m |
Main hook single load kg | 16000 |
Main hook single elevating speed m/min | 76 |
Auxiliary hook single load kg | 1500 |
Auxiliary hook single elevating speed m/min | 55 |
Engine model | YZ4DB2-40 |
Displacement/rated power(ml/kw) | 4087/90 |
Horsepower | 120 |
Derailleur model | 17D32F1 |
Wheelbase(Front/Rear) (mm) | 1775/1675 |
Wheel base(mm) | 4400 |
Max speed (km) | 80 |
Tires | 9.00-20 with spare tires (6 pieces tires) |
Emission Standard | GB17691-2005 National IV Emission,GB3847-2005 |
Axle | 2 |
Passengers | 3 |
Braking form | Vacuum booster |
Steering form | GBΦ1000 Tooth ,Material 50MN Intermediate frequency |
Crane arm structure | U shape boom(multi shape boom) |
Main Lifting Mechanism | Category two planet wheel with a brake inside |
Auxiliary Lifting Mechanism | Category one gear brake motor |
Swing Bearing | 11.40.1120 |
Vertical hydraulic leg | HSG125/90-550 |
Horizontal hydraulic leg | HSG35/63-1400 |
Platform | Anti-skidding and big |
Dynamic Motor | A2F55W |
Crane Cab | Tailor-made |
The central axially symmetrical | Five oil ways |
Crane Start | Tailor-made |
Throttle | Hydraulic |
Warning Horn | Mono snail |
Pressure gage and switch | Shockproof component |
Power Takeoff | Driving indoor operation zip type |
Hydraulic Oil Tank | Turntable rear mounted, counter weight combined type, special four-layer filters |
Advantages
The boom structure adopts WISCO BS700 high-strength and high-toughness manganese steel sheet, and the shape adopts 7m×5-section U-shaped anti-folding boom.
Hoisting mechanism Double hook double hoisting, hydraulic winch for engineering vehicles
Slewing mechanism 1.4 m internal tooth turntable, two-stage planetary reducer, central radio guide rotary structure.
Leg design High-strength composite leg box steel with 70 manganese steel, side H-shaped double-legged shape with rear legs, 4 side attached
The service brake is hydraulically assisted and the brake is the brake brake.
Hydraulic system adopts double pump combined flow, multi-way valve single connecting rod, power take-off force, aluminum material forced air cooling radiator
Engine data Yuchai Guo V emission YC4E140-56 engine
Other fully flat walkway, rear operating room, box girders, motor, composite legs,
