Home > Products > wheeled backhoe loader excavator Cheap small backhoe loader price in india

wheeled backhoe loader excavator Cheap small backhoe loader price in india

Click on the image to view the original image

Product：	views：6wheeled backhoe loader excavator Cheap small backhoe loader price in india
Branch：	heng wang
Type：	Backhoe Loader
Size：	55X17X26 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:43

Product Details

Overview

Quick Details

Dimension(Long * Breadth * High):: 5500*1700*2650mm

Warranty:: 2 Years

After-sales Service Provided:: Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Free spare parts

Applicable Industries:: Manufacturing Plant, Farms, Construction works

Condition:: New

Brand Name:: heng wang

Place of Origin:: Shandong, China

Type:: Backhoe Loader

Moving Type:: Wheel Loader

Hydraulic Cylinder Brand:: Eaton

Hydraulic Pump Brand:: Parker

Hydraulic Valve Brand:: Kawasaki

Engine Brand:: CHANGCHAI

Product name:: wheeled backhoe loader excavator Cheap small backhoe loader price

Engine:: Diesel Engine

Model:: HW10-20

Rated Power:: 37KW

Operating weight:: 3300kg

Bucket capacity:: 0.3 M3

Engine power:: 36.8/37kw

Tire:: 16/70-20

Name:: wheeled backhoe loader excavator Cheap small backhoe loader price

Load capacity:: 0.5m3

Packaging & Delivery

Selling Units:: Single item

Single package size:: 55X17X26 cm

Single gross weight:: 33.0 kg

Lead Time:

Quantity(Set)	1 - 1	>1
Est. Time(days)	10	To be negotiated

Product Description

HW10-20

No.	Item	Data
1	Transportation dimension	550017002650mm
2	Total operating weight	3300kg
3	Rated power	37kw
4	Backhoe bucket capacity	0.1m³
5	loading bucket capacity	0.5m³
6	Max digging force	25KN
7	Max digging up force	36KN
8	Travel speed	0-26km/h
9	Grade ability	25%
10	Minimum turning radius	4500mm
11	System working pressure	16MPa
12	maximum digging radius	2900mm
13	Maximum Digging Depth	1800mm
14	Backhoe Maximum dumping height	1850mm
15	Face shovel maximum dumping height	2800mm
16	Face shovel maximum dumping distance	900mm
17	Face shovel action time	12s
18	wheel base	2630mm
19	wheelbase	2670mm
20	Tire model	20.5-16
21	Tire pressure	350Mpa
22	The transmission form	Hydraulic
23	The braking system	Hydraulic

HW15-26

Item	Data
Transportation dimension	580018502700mm
Total operating weight	4800kg
Rated power	490Engine turbocharging 55kw/No turbocharging 39kw
Backhoe bucket capacity	0.15m³
loading bucket capacity	0.9m³
Max digging force	28KN
Max digging up force	36KN
Travel speed	0-26km/h
Grade ability	25%
Minimum turning radius	4500mm
System working pressure	16MPa
maximum digging radius	4600mm
Maximum Digging Depth	2800mm
Backhoe Maximum dumping height	2000mm
Face shovel maximum dumping height	3300mm
Face shovel maximum dumping distance	900mm
Face shovel action time	12s
wheel base	1550mm
wheelbase	2150mm
Tire model	20.5-16
Mpa Tire pressure	280
The transmission form	Hydraulic
The braking system	Air assist

HW15-28

Item	Data
Transportation dimension	650019602800mm
Total operating weight	5400kg
Rated power	4102Engine turbocharging 76kw/No turbocharging 60kw
Backhoe bucket capacity	0.2m³
loading bucket capacity	1m³
Max digging force	28KN
Max digging up force	42KN
Travel speed	0-28km/h
Grade ability	25%
Minimum turning radius	4500mm
System working pressure	16MPa
maximum digging radius	4300mm
Maximum Digging Depth	2600mm
Backhoe Maximum dumping height	2300mm
Face shovel maximum dumping height	3500mm
Face shovel maximum dumping distance	900mm
Face shovel action time	12s
wheel base	1630mm
wheelbase	2670mm
Tire model	16/70-20
Mpa Tire pressure	350
The transmission form	Hydraulic
The braking system	Air assist

HW15-30

No.	Item	Data
1	Transportation dimension	650020402800mm
2	Total operating weight	6000
3	Rated power	Yunnei 4108 90kw
4	Backhoe bucket capacity	0.25m³
5	loading bucket capacity	1.2m³
6	Max digging force	28KN
7	Max digging up force	42KN
8	Travel speed	0-28km/h
9	Grade ability	25%
10	Minimum turning radius	4500mm
11	System working pressure	16MPa
12	maximum digging radius	4300mm
13	Maximum Digging Depth	2600mm
14	Backhoe Maximum dumping height	2300mm
15	Face shovel maximum dumping height	3500mm
16	Face shovel maximum dumping distance	900mm
17	Face shovel action time	12s
18	wheel base	1630mm
19	wheelbase	2670mm
20	Tire model	16/70-20
21	Mpa Tire pressure	350
22	The transmission form	Hydraulic
23	The braking system	Hydraulic
