CNC hydraulic turret copper busbar punching cutting shearing processing machine

Click on the image to view the original image

Product：	views：10CNC hydraulic turret copper busbar punching cutting shearing processing machine
Branch：	Luheng
Type：	HYDRAULIC PIPE BENDERS
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:41

Product Details

Overview

Quick Details

Name:: Hydraulic busbar processing machine

Dimension:: 850mm(L)x750mm(W)x1100mm(H)

Input voltage:: Single phase 50Hz,220V (we can meet your need)

Rating oil pressure:: 700kg/cm2

Cutting Force:: 15T

Cutting Range:: 150mm(Width)X12mm(Thickness)

Punching Force:: 35T

Distance from hole to sheet side:: 110mm

Weight:: 220kg

Functions:: three functions, cutting, punching and bending

Place of Origin:: Shandong, China

Model Number:: LH-200

Brand Name:: Luheng

Type:: HYDRAULIC PIPE BENDERS

Supply Ability

Supply Ability:: 1000 Set/Sets per Year

Packaging & Delivery

Packaging Details: wooden case

Port: Qingdao

Product Description

Product Application

Multi-function Busbar Processing Machine VHB-401
Function:
1. This machine is the light of foreigh advanced products, combined with the actual situation in China, in order to improve work efficiency.
2. To save hours of work, while the design and manufacture.
3. Suitable for transmission and distribution in a large workshop and site work, construction, and power distribution cabinets and switch cabinets, etc.
4. The use of electrical applinces factory.
5. The machine is equipped with: bending, cutting, punching functionality.
6. Optional foot switch or wire switch, easy to operate.
7.legant, compact design.
Feature:
1. This machine is the light of foreigh advanced products, combined with the actual situation in China, in order to improve work efficiency.
2. To save hours of work, while the design and manufacture.
3. Suitable for transmission and distribution in a large workshop and site work, construction, and power distribution cabinets and switch cabinets, etc
4. The use of electrical applinces factory
5. The machine is equipped with: bending, cutting, punching functionality
6. Optional foot switch or wire switch, easy to operate.

SPECIFICATIONS
Functions	three functions, cutting, punching and bending
Dimension	850mm(L)x750mm(W)x1100mm(H)
Input voltage	Single phase 50Hz,220V (we can meet your need)
Rating oil pressure	700kg/cm2
Cutting Force	15T
Cutting Range	150mm(Width)X12mm(Thickness)
Punching Force	35T
Punching Dies	Impact( Φ7, 9, Φ10.5, Φ13.8, Φ17, Φ20.5)
Distance from hole to sheet side	110mm
Weight	220kg
