Home > Products > 220V electric edging power trowel 24 inch power trowel

220V electric edging power trowel 24 inch power trowel

Click on the image to view the original image

Product：	views：4220V electric edging power trowel 24 inch power trowel
Branch：	LUHENG
Type：	Honda GX690
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:41

Product Details

Overview

Quick Details

Power Source:: Gasoline

Power(W):: 5.5HP

Dimension(L*W*H):: 1980 X 996 X 1320MM

Condition:: New

Place of Origin:: Shandong, China

Brand Name:: LUHENG

Model Number:: LHS - 96

Voltage:: 220V 380V

Weight:: 310 KG

Certification:: ISO CE

Working diameter:: L1900 X W915 MM

Max. output kw(hp):: 17.9 (24)

Weight (kg):: 392

Max. speed:: 3600 rpm

Fuel tank:: 15.5 liter

Speed (rpm):: 120 - 140

Type:: Honda GX690

Engine:: Air-cooled, 4-cycle, Gasoline

stock:: in stock

Name:: power trowel

After-sales Service Provided:: Engineers available to service machinery overseas

Warranty:: 1 Year

Supply Ability

Supply Ability:: 1000 Set/Sets per Month power trowel machine

Packaging & Delivery

Packaging Details: wooden case for power trowel machine

Port: Qingdao

220V electric edging power trowel 24 inch power trowel

220V electric edging power trowel 24 inch power trowel - LUHENG 220V electric edging power trowel 24 inch power trowel - LUHENG 220V electric edging power trowel 24 inch power trowel - LUHENG

Product Instruction

1. Appearance using fluent without acute Angle design, make the operator more safety

2. The dish be made with alloy cold rolled sheet to ensure machine strong and durable

3. Machine shell adopt electrostatic coating tech, not only beautiful but also eliminate the influence of corrosion on the machine

4. adjustment Angle precisely

5. Adjustable plate diameter, applicable to different work environment, more convenient

6. superior transmission gearbox, powerful and reliable, mute, aluminum casing is easy to heat dissipation

7. Increase to improve work efficiency, more than 20% faster than traditional models

8. Equipped with oil level display table

Technology Parameters

Model	DMGS-96		DMGS-80		DMGS-78		DMGS-65
Weight (kg)	392		310		325		295
Dimension (mm)	L2540 X W1240 X H1300		L1980 X W996 X H1320		L1980 X W1020 X H1500		L1710 X W940 X H1150
Working diameter (mm)	L2475 X W1175		L1900 X W915		L1890 X W915		L1570 X W750
Speed (rpm)	120 - 140		120 - 140		150 - 155		140
Engine	Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline
Type	Honda GX690	Kohler 34HP	Honda GX690	Kohler Pro25	Honda GX690	Kohler Pro25	Honda GX390	Kohler Pro14
Max. output kw(hp)	17.9 (24)	25.4 (34)	17.9 (24)	17.2 (23)	17.9 (24)	17.2 (23)	9.6 (13)	10.5 (14)
Max. speed (rpm)	3600		3600		3600		3600
Fuel tank (liter)	15.5		15.5		12		6.5
