solar water pump complete set with panel etc, solar battery pump, solar pump with internal MPPT controller
1) The whole system consists of solar panel array, con lowest price solar water pump from manufacture troller and submersible well pump
2) The pump is directly connected to solar panels without inverter, and the controller
protects the pump, achieve high efficiency and make fullest use of solar energy.
3) The solar panel absorbs the sunlight and transfer it into DC electrical energy for the
driving of submersible water pump.
4) It adopts lightning protection, water filling, permanent magnet, brushless DC, and
nonsensor shielding motor, and MPPT (maximum power point tracking) driving device.
5) According to the changes of the intensity of sunlight in real time, MPPT controller adjusts output frequency to track the maximum power point.
Model | Impeller | voltage (V) | Power (kW) | Max Flow (M3/H) | Solar panel power | Max Head (M) | Outlet (IN) | Outer Diameter (MM) | Weight (KG) |
3LH0.9/32-D12/100 | Screw | 11--18 | 80--220 | 0.9 | 200w | 32 | 0.75" | 76*460 | 6.7 |
3LH1.0/30-D24/80 |
| 22-36 | 45-150 | 1 | 150w | 30 | 0.75" |
| 7 |
3LH1.3/50-D24/140 |
| 22-36 | 80-200 | 1.3 | 200w | 50 | 0.75" |
| 7.2 |
3LH1.5/80-D24/210 |
| 22-36 | 100-270 | 1.5 | 270w | 80 | 0.75" |
| 7.5 |
3LH1.5/100-D24/270 |
| 22-36 | 140-350 | 1.5 | 360w | 100 | 0.75" |
| 8 |
3LH1.5/120-D36/500 |
| 32-54 | 320-800 | 1.5 | 800w | 120 | 0.75" |
| 9 |
3LH2.3/80-D48/500 |
| 42-72 | 480-950 | 2.3 | 1000w | 140 | 0.75" |
| 9 |
3LH2.3/110-D48/750 |
| 42-88 | 600-1200 | 2.3 | 1200w | 160 | 0.75" |
| 9.5 |
3LH2.3/125-D72/1000 |
| 42-88 | 800-1500 | 2.3 | 1500w | 180 | 0.75" |
| 9.5 |
3LHI0.9/32-D12/100 | Screw | 11--18 | 80--220 | 0.9 | 220w | 32 | 0.75" |
| 6.7 |
3LHI1.5/50-D24/140 |
| 22-36 | 80-200 | 1.3 | 200w | 50 | 0.75" |
| 7.2 |
3LHI1.5/80-D24/210 |
| 22-36 | 100-270 | 1.5 | 280w | 80 | 0.75" |
| 7.5 |
3LHI1.5/100-D24/270 |
| 22-36 | 140-350 | 1.5 | 360w | 100 | 0.75" |
| 8 |
4LH2.5/50-D24/270 | Screw | 22-36 | 140-350 | 2.5 | 360w | 50 | 1" | 100*480 | 9.5 |
4LH3/60-D36/500 |
| 32-54 | 300-700 | 3 | 700w | 60 | 1" |
| 10 |
4LH3.6/80-D48/750 |
| 42-72 | 450-1000 | 3.6 | 1000w | 80 | 1" |
| 10.5 |
4LH4/100-D72/1000 |
| 42-88 | 600-1300 | 4 | 1200w | 100 | 1" | 100*550 | 13.5 |
4LH3/120-D72/1000 |
| 42-88 | 800-1550 | 3 | 1600w | 120 | 1" |
Q1. How long is your warranty?
Answer: 1 year.
Q2. Do you provide After- sales service parts?
Answer: Of course, We could provide easy- consumable spares.
Q3.How about your price?
Answer: Based on high quality, Our price is very competitive in the world.
Q4.How about your customer service?
Answer: For email, we could reply our customers" emails within 2 hours.
Q5.What is your terms of payment ?
Answer:T/T
