- Type:
- Rock Splitter
- Applicable Industries:
- Construction works
- Condition:
- New
- Application:
- Rock splitter
- Motor Type:
- DC Motor
- Place of Origin:
- Shandong, China
- Brand Name:
- LH
- Dimension(L*W*H):
- 450*410*700MM
- Certification:
- ISO
- Warranty:
- 1 Year
- After-sales Service Provided:
- Online support, Video technical support, Good Quality Hydraulic rock splitter, Quarry Stone Cutting Machine
- length of the wedge:
- 380mm
- Crack width of a division:
- 10~40mm
- Theoretical splitting force:
- 640t
- The actual split force:
- 600t
- Minimun drilling depth:
- 800mm
- Bore diameter:
- 45-50mm
- capacity of tank:
- 40-90L
- working pressure:
- 55-60Mpa
- working flo:
- 2-13L/Min
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 45X41X70 cm
- Single gross weight:
- 32.0 kg
- Package Type:
- export standard packing for Good Quality Hydraulic rock splitter, Quarry Stone Cutting Machine
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Set) 1 - 10 >10 Est. Time(days) 15 To be negotiated
hydraulic rock stone splitting machine
hydraulic rock stone splitting machine,also known as splitting machine,split stone machine,muntain machine,etc..according to the power station type can be divided into:electric type rock splitter,diesel rock splitter,gasoline type rock splitter,four kinds of air motor.According to split gun materail can be divided into :steel split gun and aluminum split gun.The main components of the concrete components(cement pavement,machine toolfoundation,brige and housing components)local and all demolition operations;natural stone mining(metal mine,non-metallic mineral).hydraulic rock stone splitting machine is particularly suitable for the second division of large rock,is a completely replace the blasting and hand disassembly,of the ideal equipment.

Model/Data Name | HW90-250-1 | HW90-250-2 | HW90-250-3 | HW90-250-4 |
piston diameter | 90mm | 90mm | 90mm | 90mm |
drilling diameter | Φ50mm | Φ42mm | Φ45mm | Φ50mm |
drilling depth | ≧600mm | ≧500mm | ≧550mm | ≧600mm |
cheese block length | 10~40mm | 10~40mm | 10~40mm | 10~40mm |
weight | 30Kg | 31Kg | 32Kg | 33Kg |
hydraulic rock stone splitting machine specification | ||||
Engine | electricity engine | Gaoline engine /diesel engine | ||
weight | 60kg | 100kg /150kg | 100kg | 130kg/150kg |
capacity of tank | 15L | 40L /88L | 45L | 65L/90L |
motor power | 1.5KW | 4KW/7.5KW | 4Hp | 7Hp/7.5Hp |
working pressure(Mpa) | 55-60 | 55-60 | 55-60 | 55-60 |
working flow(L/min) | 2-13 | 2-13 | 2-13 | 2-13 |
configurable splitting machine number | 1-5 | 2-7/2-10 | 1-3 | 3-8/3-10 |
Advantage for hydraulic rock stone splitting machine
1) High efficiency(Max:100T),it can split the stone and concrete easily.
2) High efficiency,it can split the stone in 5-10seconds.
3) Long life,the wedges stands wear and tear.
4) Easy to operate and mintain.
5) Now it is widely used in mineral mining(cave mining),civil engineering construction and demolition,.It is also an indispensable tool in construction ,river dreging,salvation ect.
6)Our main models of hydraulic pump and cylinder are as follows.If you are interested in,please let us know which type of pump and cylinder you need.We will offer a very competitive price for you.



hydraulic rock stone splitting machine
Diesel engine power
diesel engine power with rock splitter gun
hydraulic rock stone splitting machine
Electric engine power
Electric engine power with rock splitter gun


hydraulic rock stone splitting machine
Hydraulic rock splitter gun,you can choose steel materail or aluminous.
hydraulic rock stone splitting machine
Hydraulic rock splitter wedge,you can choose diffrent length of it.









Packing for hydraulic rock stone splitting machine:
We will send the hydraulic rock splitter picture which you have orderd, then packing it with standard export wooden box after you have confirmed the machine is ok .
Different machines" package will be different. We usually supply export wooden box ,carton box package. If it is a big machine and production line machine , it will be loaded in the container directly .
Delivery for hydraulic rock stone splitting machine:
1. Delivery by sea :After it was delivered to the seaport . We will tell you the shipping time and arrival time . Finally, we"ll send you all original documents by Express for free .
2.Delivery by Express to your door (DHL/TNT/Fedex/UPS etc ) or by air to your city airport . We will tell you the Express tracking number .
3.Deliver it to the warehouse which you have requested . We will tell you logistic or express tracking number .


Jining Luheng Machinery Equipment Co.,Ltd.
Jining Luheng Machinery Equipment Co.,Ltd. is the professional manufacturer of rock splitter. With more than 300 workers and 25 Senior engineers,high quality produts and best after sales service can both be guaranteed. main clients are around Southeast Asia,Mid East and South America. Welcome visit our factory and sent inquiry to us.



MOQ,Payment,Loading port,price term,OEM
1.Payment : I:100% T/T
II:30% advaced and the balance paid before delivery
III:credit letter at sight
2.MOQ:1Pcs
3.Port of loading: Qingdao Port or others
4.Price term:FOB Qingdao price
5.OEM:we are pleased to be your OEM factory
Contact us for more details about price,packing,shipping and discount.
TRUST YOU WILL LIKE OUR DESIGNS & PRICE.
