LHH hot sale construction hydraulic auger drilling rig pile driving machine / screw pile driver
Click on the image to view the original image
Product： views：11LHH hot sale construction hydraulic auger drilling rig pile driving machine / screw pile driver
Branch： HW
Size： 600X230X200 cm
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 19:43
  Negotiated
Product Details
Overview
Quick Details
Piling Speed(m/min):
3m/min
Efficiency:
High Efficiency
After-sales Service Provided:
Video technical support
Warranty:
1 Year
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HW
Weight:
19T
Dimension(L*W*H):
11400*2400*3300mm
Certification:
ISO
Engine power:
85KW/2200r/min
Maximum torque:
425N.M
Engine brand:
Changcai engine
Maximum pressure force:
90KN
Maximum lifting force:
100KN
Drilling diameter:
500-1200mm
Max drilling depth:
20m
Maximum travel speed:
3.6km/h
Working dimension:
5800*2400*1250mm
Transportation dimension:
11400*2400*3300mm

Packaging & Delivery

Selling Units:
Single item
Single package size:
600X230X200 cm
Single gross weight:
6500.0 kg
Lead Time:
Quantity(Set)1 - 5>5
Est. Time(days)10To be negotiated
Product Description

Product Application

● Advanced mobile type, quick to transfer from transportation to working mode.
● High safety standard, satisfying dynamic and static stability requirements, ensuring safe working.
● Optimized luffing mechanism, working stable, easy to maintenance.
● Innovative drilling bucket depth measurement system, showing a higher accuracy than conventional pile driver.
● Bottoming protection and priority control function of main winch, making it easier to operate.
● Multi-stage of vibration-proof power head, ensuring it working more stable.
● Mast can adjust vertical property automatically, making it to drill more precise.
● Humanized cabin design, with large space.
● Secondary operating interface, more convenient using.
● Efficient energy-saving turbocharged water-cooled diesel engine.
● Excellent fuel system
● Advanced cooling system
● Intelligent Control System

SPECIFICATIONS FOR HAMMER PILE DRIVER





Engine
Rated Power
Kw
85KW/2200r/min
Maximum torque
N.M
425N.M
engine type
Turbocharged
Maximum lifting force
KN/m
100KN/m
Maximum lifting speed
m/min
45m/min
Inclination (left and right)
±4°
Inclination (Front and back)
5°





Hydraulic hammer Part
Drilling diameter
MM
500-1200
drilling depth
M
20
Maximum travel speed
3.6km/h
Maximum gradeability
30°
Maximum stroke
MM
2500mm
Transportation dimension
L*W*H
11400*2400*3300mm
Working dimension
Workshop Manufacture

              Welcome to visit our factory .


            You will get more from our factory.


Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
5523 (L) * 2456 (W) * 1789 (D)
Weight
8T



Packaging Details


   The normal package is just like photos shown , if you have another requirement ,please tell me in advance ,we will packed as your need.
Packaging
Size
5523 (L) * 2456 (W) * 1789 (D)
Weight
8T



Packaging Details



The normal package is just like photos shown , if you have another requirement ,please tell me in advance ,we will packed as your need.
