Home > Products > smoothing concrete power float trowel for road construction

smoothing concrete power float trowel for road construction

Click on the image to view the original image

Product：	views：11smoothing concrete power float trowel for road construction
Branch：	LUHENG
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:43

Product Details

Overview

Quick Details

Power Source:: Gasoline

Power(W):: 5.5HP

Dimension(L*W*H):: 1980 X 996 X 1320MM

Condition:: New

Place of Origin:: Shandong, China

Brand Name:: LUHENG

Model Number:: DMGS-96

Voltage:: 220V 380V

Weight:: 310 KG

Certification:: ISO

Model:: DMGS-96

Max. speed::: 3600 rpm

Fuel tank::: 15.5 liter

Working diameter::: L1900 X W915 MM

Weight (kg):: 392

Speed (rpm):: 120 - 140

Max. output kw(hp):: 17.9 (24)

Voltage::: 220V 380V

Power Source::: Gasoline

Warranty::: 1 year

After-sales Service Provided:: Engineers available to service machinery overseas

Warranty:: 1 yeas

Supply Ability

Supply Ability:: 10000 Set/Sets per Year

Packaging & Delivery

Packaging Details: wooden case

Port: QINGDAO

smoothing concrete power float trowel for road construction

Road Building Construction Tools and Equipment Power Trowel

Product Instruction

1. Appearance using fluent without acute Angle design, make the operator more safety

2. The dish be made with alloy cold rolled sheet to ensure machine strong and durable

3. Machine shell adopt electrostatic coating tech, not only beautiful but also eliminate the influence of corrosion on the machine

4. adjustment Angle precisely

5. Adjustable plate diameter, applicable to different work environment, more convenient

6. superior transmission gearbox, powerful and reliable, mute, aluminum casing is easy to heat dissipation

7. Increase to improve work efficiency, more than 20% faster than traditional models

8. Equipped with oil level display table

smoothing concrete power float trowel for road construction

Technology Parameters

Model	DMGS-96		DMGS-80		DMGS-78		DMGS-65
Weight (kg)	392		310		325		295
Dimension (mm)	L2540 X W1240 X H1300		L1980 X W996 X H1320		L1980 X W1020 X H1500		L1710 X W940 X H1150
Working diameter (mm)	L2475 X W1175		L1900 X W915		L1890 X W915		L1570 X W750
Speed (rpm)	120 - 140		120 - 140		150 - 155		140
Engine	Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline		Air-cooled, 4-cycle, Gasoline
Type	Honda GX690	Kohler 34HP	Honda GX690	Kohler Pro25	Honda GX690	Kohler Pro25	Honda GX390	Kohler Pro14
Max. output kw(hp)	17.9 (24)	25.4 (34)	17.9 (24)	17.2 (23)	17.9 (24)	17.2 (23)	9.6 (13)	10.5 (14)
Max. speed (rpm)	3600		3600		3600		3600
Fuel tank (liter)	15.5		15.5		12		6.5
