LH company Hydraulic Vibro Hammer/Vibratory Sheet Pile Driver
Click on the image to view the original image
Product： views：8LH company Hydraulic Vibro Hammer/Vibratory Sheet Pile Driver
Branch： HW
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 19:44
  Negotiated
Product Details
Overview
Quick Details
Piling Speed(m/min):
2.7m/min
Efficiency:
High Efficiency
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HW
Model Number:
HZY-300L
Weight:
2200KG
Dimension(L*W*H):
3900*2000*2600mm
Certification:
ISO9001/CE
Rated pressure:
20Mpa
Displacement:
2000ml/r
Product Name:
ground screw used pile driver
Drilling depth:
1~10m
Drilling diameter:
40~300mm
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
280 Set/Sets per Month Hydraulic Vibro Hammer
Packaging & Delivery
Packaging Details
regular packaging
Port
qingdao/dalian/shenzhen/ningbo/shanghai
Factory
Product Description

Product Application

Pile driving speed,the average 3 minutes can realize piling 6 meters deep,namely a hole 3 minutes to play.Oil province,is a common driver uses around half of a year can be a driver left money for you.Bit using manganese steel manufacturing,through processing,are suitable for all kinds of geological environment.

Crawler walking,high walking and climbing ability The frame can be moved back and forth,bit can be adjusted,high piling position accuracy.

Specification
Model
HZY-300L
Rated power
20Mpa
The rated torque
6000n.m
Displacement
2000ml/r
Maximum torque
7000n.m
Engine model
4102
Enigne rotary speed
2500r/min
Crawler width
350mm
Crawler length
1.8m
Walking motor displacement
1300ml/r
Walking motor rated power
16Mpa
Walking motor  Maximum torque
3000n.m
Walking motor speed
50r/min
Drilling rod diameter
40~300
Drilling depth
0~10
Air consumption
6~8m3/min
Size
3.9m*2.0m*2.6m
Weight
2300kg
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
