Factory direct doser pump,discount compact design e dose dosing pump skype:sunnylh3

Click on the image to view the original image

Product：	views：6Factory direct doser pump,discount compact design e dose dosing pump skype:sunnylh3
Branch：	LH
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:44

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: LH

Model Number:: LH-GM

Structure:: Diaphragm Pump

Usage:: Chemical

Application:: Metering

Power:: Electric

Fuel:: electric

Pressure:: High Pressure

Name:: Metering pump

steady precision:: ±2%

Highest pump discharge head:: 12BAR

max inlet pressure:: 2BAR

Single-head max. flow:: 1800L/h

Adjustment ratio:: 10:1

Standard or Nonstandard:: Standard

Theory:: Electromagnetic Pump

Supply Ability

Supply Ability:: 1000 Set/Sets per Month

Packaging & Delivery

Packaging Details: Packaging Details:regular packaging

Port: qingdao

Factory direct doser pump,discount compact design e dose dosing pump skype:sunnylh3

Product Introduction

Features:

1. Safe operation, mechanical drive diaphragm.

2 .Sealing, no leakage, simple and safe assembly and maintenance.

3 .It can transmit high-viscosity media, corrosive liquids and hazardous chemicals.

4. Flow regulator can adjust the stroke length or motor frequency.

5 .It is a multi-layer composite membrane structure repression, the first layer of super toughness Teflon acid film, the second layer of EPDM rubber elasticity, the third layer 3.0mmSUS304 supporting core, the fourth layer is made of reinforced nylon fiber fill, the fifth layer using EPDM rubber elasticity completely wrapped shoe, which can effectively raise up the diaphragm pot life.

Chemical Dosing Pump Application:
The Series LH-GM Metering Pump is designed for high output applications. The drive incorporates a variable eccentic design which ensures smooth output and reduces system shock. The mechanically actuated diaphragm reduces the possibility of hydraulic oil contamination of process liquid which makes this an ideal pump for water treatment applications. DC variable speed drives are available for external control and automation.

The metering pumps offer a high level of reliability with outstanding value for applications up to 175 psi (12 Bar).

Technology Parameters

Model	Capacity (LPH)		Max. Pressure (Bar)	Dia. plunger (mm)	Stroke (mm)	Speed (min-1)	Motor power (KW)	Weight (KGS)
Model	50Hz	60Hz	Max. Pressure (Bar)	Dia. plunger (mm)	Stroke (mm)	Speed (min-1)	Motor power (KW)	Weight (KGS)
GM1.6-2.1/50	2.1	2.52	500	5	20	106	0.55	40
GM1.6-2.1/20	2.1	2.52	200			106	0.37
GM1.6-2.7/50	2.7	3.24	500			135	0.55
GM1.6-2.7/20	2.7	3.24	200			135	0.37
GM1.6-3/40	3	3.6	400	6		106	0.55
GM1.6-3/20	3	3.6	200			106	0.37
GM1.6-4/40	4	4.8	400			135	0.55
GM1.6-4/20	4	4.8	200			135	0.37
J1.6-5.6/25	5.6	6.72	250	8		106	0.55
GM1.6-5.6/12.5	5.6	6.72	125			106	0.37
GM1.6-7.2/25	7.2	8.64	250			135	0.55
GM1.6-7.2/8	7.2	8.64	80			135	0.37
GM1.6-9/20	9	10.8	200	10		106	0.55
GM1.6-9/6.3	9	10.8	63			106	0.37
GM1.6-11.5/20	11.5	13.8	200			135	0.55
GM1.6-11.5/8	11.5	13.8	80			135	0.37
GM1.6-1312.5	13	15.6	125	12		106	0.55
GM1.6-13/6.3	13	15.6	63			106	0.37
GM1.6-16.5/10	16.5	19.8	100			135	0.55
GM1.6-16.5/40	16.5	19.8	40			135	0.37
GM1.6-23/8	23	27.6	80	16		106	0.55
GM1.6-23/3.2	23	27.6	32			106	0.37
GM1.6-30/6.3	30	36	63			135	0.55
GM1.6-30/2	30	36	20			135	0.37
GM1.6-36/5	36	43.2	50	20		106	0.55
GM1.6-36/2	36	43.2	20			106	0.37
GM1.6-46/40	46	55.2	40			135	0.55
GM1.6-46/1.3	46	55.2	13			135	0.37
GM1.6-58/3.2	58	69.6	32	25		106	0.55
GM1.6-58/1.3	58	69.6	13			106	0.37
GM1.6-72/2.5	72	86.4	25			135	0.55
GM1.6-72/1	72	86.4	10			135	0.37
GM1.6-80/2	80	96	20	30		106	0.55
GM1.6-80/1	80	96	10			106	0.37
GM1.6-105/2	105	126	20			135	0.55
GM1.6-105/0.8	105	126	8			135	0.37
GM1.6-95/2	95	114	20	32		106	0.55
GM1.6-95/1	95	114	10			106	0.37
GM1.6-120/1.6	120	144	16			135	0.55
GM1.6-120/0.8	120	144	8			135	0.37
GM1.6-160/1.3	160	192	13	36		135	0.55
GM1.6-160/0.8	160	192	8	36			0.37
GM1.6-190/1	190	228	10	40			0.55
GM1.6-190/0.63	190	228	6.3	40			0.37
