200m truck mounted bore water well drilling rig - LUHENG

Click on the image to view the original image

Product：	views：6200m truck mounted bore water well drilling rig - LUHENG
Branch：	well drilling rig
Type：	hydraulic well drilling rig
Size：	10X20X30 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:44

Product Details

Overview

Quick Details

Applicable Industries:: Construction works , Energy & Mining

Condition:: New

Type:: hydraulic well drilling rig

Power Type:: Diesel

Place of Origin:: Shandong, China

Brand Name:: well drilling rig

Usage:: Water Well

Voltage:: 220V/380V

Dimension(L*W*H):: 2500-900*1500 mm

Weight:: 1800 kg

Certification:: ISO9001

Warranty:: 1 Year

After-sales Service Provided:: Video technical support, Online support

Name:: well drilling rig

maximum open hole caliber:: 300 mm

end hole caliber:: 75 mm

drill rod caliber:: 60 mm

spindle speed:: forward 30-1050 r/min,reverse 29-137 r/min

spindle stroke:: 600 mm

max.single line lifting capacity:: 4000 kg

wirerope caliber:: 12.5 mm

wirerope lenght:: 50 m

reel diameter:: 300 mm

Packaging & Delivery

Selling Units:: Single item

Single package size:: 10X20X30 cm

Single gross weight:: 60.0 kg

Package Type:: wooden case for 200m truck mounted bore water well drilling rig

Lead Time:

Quantity(Set)	1 - 1	>1
Est. Time(days)	14	To be negotiated

Mud Pump Drilling Rig Portable Water Well Geotechnical Drills for deep well / whatsapp +8613665375638

Product Description

1.HW brand water well drilling rig Features
a. the machine can be equipped with crawler chassis/trailer/wheel /truck device,easy to move with fast speed.
b. hydraulic oil pressure feed device,improve drilling efficiency.
c. pressure gauge display the condition of the bottom of the drill hole.
d. drill mast controlled by hydraulic cylinder,improve the efficiency diesel engine adopt the electric starter,to reduce the labor itensity.

2. HW brand Water Well Drilling Rig Applications
HW drilling rig is mainly used for geological general investigation and exploration,road and tall buliding foundation exploration,kinds of hole in concrete structure,river levees,subgrade grouting hole,drilling and driect grouting,civil wellsand earth temperature central air-conditioner,etc.

Water well drilling rig HW-160/190/230 technical parameter:
