CNC Copper Turret Hydraulic Busbar Processing Bending Cutting Punching Machine

Click on the image to view the original image

Product：	views：9CNC Copper Turret Hydraulic Busbar Processing Bending Cutting Punching Machine
Branch：	HW
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 19:44

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: HW

Dimension(L*W*H):: 1500*1300*1200mm

Model Number:: GE-33NR

Name:: busbar processing machine

Punching Max pressure(KN):: 350KN

Punching dia.(mm):: 4.3-25

Punching Max thickness(mm):: 12

Punching Max width(mm):: 150

Cutting Max thickness(mm):: 12

Cutting Max width(mm):: 150

Bending Max pressure (KN):: 350

Bending Max width(mm):: 150

Bending Max thickness(mm):: 12

Condition:: New

Warranty:: 1 Year

Power Source:: Hydraulic

After-sales Service Provided:: Overseas third-party support available

Voltage:: 220V/380V(According

Certification:: ISO9001

Power(W):: 3*4kw

Weight:: 1250KG

CNC or Not:: CNC

Supply Ability

Supply Ability:: 100000 Set/Sets per Year

Packaging & Delivery

Packaging Details: Standard export wooden package

Port: Qingdao/Shanghai

Lead Time:: Shipped in 3 days after payment

CNC Copper Turret Hydraulic Busbar Processing Bending Cutting Punching Machine

Product Introduction

This busbar processing machine is special for processing aluminum and copper busbars used in electric power, high/low voltage electric apparatus and busway industries.

It combines Cutting, Punching (various round hole and rectangular hole), horizontal bending, Vertical bending , Embossing, Pressing Cable joint, Twisting, reverse flattening of Copper and Aluminium busbarsfor Copper or Aluminium bus bars.Three units may work together and do not effort each other.

The production efficiency can be increased remarkably by using this machine with comparison to other traditional processing equipments and also it brings convenience.

Features:

1. Low maintenance ,longer service life.

2. The cut surface is smooth and neat, no droop, no burrs, no waste.

3. Rotary turret punch unit installed 6 dies, less replacing, high efficiency.

4. three work positions can be used at the same time.

5. Controlled by PLC, bending precision at ±1 degree and repeat degree at ±0.3 degree.

6. Easily to be moved with four castors.

7. Manual button and foot switch are optional.

8. Adjustable working stroke.

9. on users requirement, special mold for special shape.

Technology Parameters

Function	Item	MODEL
Function	Item	GE-33NR	GE-50NR	GE-33SNR	GE-50SNR
Punching	Max. Punching Force (KN)	350	500	350	500
	Punching Diameter Range (MM)	Ø4.3-Ø25	Ø4.3-Ø34	Ø4.3-Ø25	Ø4.3-Ø34
	Max. Thickness (MM)	12	16	12	16
	Max. Width (MM)	150	200	150	200
Shearing/Cutting	Max. Shearing Thickness (MM)	12	16	12	16
Shearing/Cutting	Max. Shearing Width (MM)	150	200	150	200
Honrizental Bending	Max. Bending Force (KN)	300	500	300	500
	Max. Thickness (MM)	150	200	150	200
	Max. Width (MM)	12	16	12	16
Vertical Bending	Max. Width (MM)	100	120	100	120
Vertical Bending	Max. Angle (Degree)	90°	90°	90°	90°
Out Dimension	MM	167012001200	180015001300	177014001300	198015501460
Power	KW	3*4kw	3*5.5kw	3*4kw	3*5.5kw
Weight	KG	1200kg	1750kg	1360kg	2200kg
CNC Precision	Bending Precision	±1°	±1°	±1°	±1°
CNC Precision	Repeat Bending Precision	±0.3°	±0.3°	±0.3°	±0.3°
