Overview
Quick Details
- Applicable Industries:
- Hotels, Manufacturing Plant, Farms, Construction works
- Condition:
- New
- Type:
- Rotary Drilling Rig, water well drill rig
- Power Type:
- Diesel
- Place of Origin:
- Shandong, China
- Brand Name:
- Hengwang
- Usage:
- Water Well
- Voltage:
- 220V/380V
- Dimension(L*W*H):
- 2500*1000*1300 mm
- Weight:
- 960KG
- Certification:
- ISO9001
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support, Free spare parts, Online support, Field installation, commissioning and training
- Drilling depth:
- 160m
- Maximum open hole caliber:
- 260mm
- End hole caliber:
- 75mm
- Drill rod caliber:
- 50mm
- Drilling angle:
- 90~75°
- Drilling rig weight:
- 560kg
- Steel wire rope diameter:
- 13mm
- Steel wire rope cubic measure:
- 27mm
- Maximum pressure:
- 1.2Mpa
Supply Ability
- Supply Ability:
- 1000 Set/Sets per Year
Packaging & Delivery
- Packaging Details
- Standard wooden case packing
- Port
- Qingdao/Shanghai
- Lead Time:
Quantity(Sets) 1 - 1 >1 Est. Time(days) 7 To be negotiated
