portable irrigation water well drilling rig for sale
Lowest price portable irrigation water well drilling rig HW80 for sale
Product Introduction
This machine mainly used for geothermal drilling, farm irrigation and water well drilling, drilling diameter is 70-300mm, and drilling depth is 60-80m.
It also can be used in small building piling, like farmhouse or factory and so on, the drilling diameter can reach 500mm and depth can be more than 10m.
1. Light weight. The main engine is only weighted 0.135tons
2. Easy to operate. Can be handled without experience.
3. Durable. The first generation of products used for 13 years, drilled more than 4000 water wells, nearly no repair record except the drilling bits.
4. Can drill through hard stratum, unless thick rock layer.
5. Can drill deep. Equipped with raser, reduce the labor intensity.
6. High efficiency, the drilling speed can reach 20meters depth per hour, in plain area.
7. Economical. It can be called the most economical water well drilling machine.
The packing of the machine is wood box, the CBM is about 2.0M3, the total weight (complete set) is about 850KG
Technology Parameters
Technical Parameters of Water Well Drilling Rig | |
Type | HL-80 |
Max. Drilling Diameter | 70-300mm |
Max. Drilling Depth | 60-80m |
Total Power | 7.5 kw |
Engine Power | 1.2kw |
Lifting Power | 1.0kw |
Pump | 2.2kw,220V(flow head 46m) |
Capacity of hoist | 1.0t |
Height of tower | 3m |
Total Weight | 700kgs(150m pipes) |
Drilling Rod Length | 2m/piece |
Diameter of Drilling Rod | 42mm |
