- Applicable Industries:
- Energy & Mining
- Condition:
- New
- Type:
- Core Drilling Rig
- Power Type:
- Gasoline
- Place of Origin:
- Shandong, China
- Brand Name:
- LH
- Usage:
- Coal
- Voltage:
- 380 V
- Dimension(L*W*H):
- 2.75*0.95*1.6m
- Weight:
- 28 kg
- Certification:
- ISO CE
- Warranty:
- 1 Year
- After-sales Service Provided:
- Online support
- length overall(mm):
- 600
- piston strock(mm):
- 24
- piston diamter(mm):
- 30
- oil flow(L/min):
- 32-35
- hydraulic pressure(Mpa):
- 15-17.5
- impact energy(J):
- 55-65
- impact frequency(HZ):
- 55-60
- torque(NM):
- 55-60
- Spin Speed(r/min):
- 250-300
- Name:
- ROCK DRILL
- Supply Ability:
- 1000 Set/Sets per Week ROCK DRILL
- Packaging Details
- wooden case ROCK DRILL
- Port
- QINGDAO
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 1 >1 Est. Time(days) 3 To be negotiated
Powerful quality yn 27 rock drill hydraulic rock drill for sale petrol rock drill price
Powerful quality yn 27 rock drill, hydraulic rock drill for sale, petrol rock drill price Powerful quality yn 27 rock drill, hydraulic rock drill for sale, petrol rock drill price
Technology Parameters
Model | YN27C |
Weight | 27kg |
overall dimension | 746*315*229mm |
engine | single cylinder, air cooled two strokes |
Cylinder diameter*stroke piston | 58*70mm |
Rotating speed of engine | more than 2450r/min |
displacement of engine | 185cm^3 |
carburetor | hand needle valve, no floating type |
Ignition system | controllable silicon contactless system |
Drilling speed | more than 2450r/min |
Max drilling depth | 6M |
Fuel consumption | 1.2L/min |
Tank capacity | more than 1:14L |
mixing ratio of gasoline and lubrication oil | 12:01 |
end of drill rod dimensions | hexagonal 22*108mm |
Rotating speed of drill rod | more than 200r/min |
Clearance of spark plug | 0.5-0.7mm |
