Click on the image to view the original image
- Applicable Industries:
- Construction works
- Condition:
- New
- Place of Origin:
- Shandong, China
- Brand Name:
- forkliftcar stacker
- Type:
- Powered Pallet Truck
- Power Souce:
- DC Motor
- Max. Lifting Height:
- 3000mm
- Min. Lifting Height:
- 100mm
- Fork Length:
- 1070mm
- Fork Width:
- 160mm
- Overall Dimensions:
- 3100*1050*2080mm
- Certification:
- ISO
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support
- Product Name:
- car stacker
- Steering mode:
- seat
- Fork Size:
- 1070*160*60mm
- Weight:
- 1600kg
- Travel Speed:
- 5km/h
- Driving motor power:
- 2.2kw
- Lifting motor power:
- 3kw
- power type:
- electric
- Power Source:
- 48v battery
- Color:
- Red
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 1X1X1 cm
- Single gross weight:
- 17.0 kg
- Package Type:
- plastic bag for forklift stacker
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Set) 1 - 1 >1 Est. Time(days) 3 To be negotiated
Electric Forklift/Stacker/Forklift truck
We have electric pallet truck,electric stacker,counterbalanced electric stacker,electric stacker with wide legs,electric reach stacker,electric reach forklift truck stand-on,electric reach forklift truck seated,
The following type is the description for full electric forklift truck , full electric stacker,etc.
1.All electric forklift stacker refers to electricity for homework, most are battery to work.
2.And the battery role is to be able to keep the limited electricity used in the right place.
3.Its working principle is to convert chemical energy into electricity.
4.All electric forklift battery built-in also is this kind of battery.
Related hydraulic forklift/Electric stacker/Pallet lift truck as follows:
electric pallet truck
electric reach stacker
electric forklift reach stacker--seated
Specifications for hydraulic forklift/Electric stacker/Pallet lift truck | ||||||
Model | HWLY1000 | HWLY1500 | HWLY2000 | |||
Load Capacity(Kg) | 1000 | 1500 | 2000 | |||
Lift Height(mm) | 3000 | 3000 | 3000 | |||
Fork Length(mm) | 1070 | 1070 | 1070 | |||
Lowest height (mm) | 100 | 100 | 100 | |||
Manipulation Way | Driving style | Driving style | Driving style | |||
Tyre | Driving style | Solid tyre | Solid tyre | |||
Dimension of Driving Wheel | 350*100 | 350*100 | 250*80 | |||
Speed at Full Load km/h | 8 | 8 | 5 | |||
Lifting Speed at full Load mm/sec | 80 | 80 | 80 | |||
Door Frame Angle ° | 3~6 | 3~6 | 3~6 | |||
Gradient at full Load° | 10 | 8 | 8 | |||
Battery V/Ah | 48/120 | 48/120 | 24/240 | |||
Working Time(for reference)(hr) | 4 | 3.5 | 3 | |||
Driving Motor(kw) | 2.2 | 2.2 | 1.5 | |||
Lifting Motor(kw) | 3 | 3 | 3 | |||
The Min. Turning Inner Radius (mm) | 1750 | 1800 | 1800 | |||
L X W X H Dimension (mm) | 3100*1050*2080 | 3100*1050*2080 | 3100*930*2080 | |||
Machine weight(kg) | 1600 | 1700 | 1800 | |||
lifting Height at each weight (mm) | 1600/2000/2500/3000/3500 | |||||
Height of Door Frame(mm) | 2080/1600/1850/2080/2350 | |||||
Main Features of hydraulic forklift/Electric stacker/Pallet lift truck:
1. Ride on type counterbalance forklift body is made of high quality steel manufacturing, during use it will never be deformed , Wide viewing gantry, Allows you to look clearly in the operation process.
2. The original United States Curtis electric control system, handle assembly. Computer programming, stepless speed regulation, acceleration and smooth. The reaction is sensitive, driving freely .
3. Standard, high-capacity battery pack, to ensure a continuous use of electricity over 6 hours.
4. Imported smart charger (unattended), to ensure that the battery life of more than five years.
5. Using the Italian import drive assembly, strong power, power break brake performance, When the upper and lower slopes, more prominent braking performance.. Will not cause uphill or downhill encountered due to lack of power caused by retrogression, especially when loading to reduce the incidence of accidents.
6. the hydraulic system is imported from the original Italy. When the load is loaded, the hydraulic system is more stable and control.
Simple worktable
.
Foot Controller
Foot control brake emergency stop device configuration
Thickened steel frame
frame with thickened steel,with headlights,wide field of vision
Comfortable seat
Comfortable seat with safety belt
Solid rubber wheel
Adapt to various road conditions
Forged fork
Made of quality steel not easy deformed
