The power is mainly equipped with a four-cylinder 490 engin,more than 50 horsepower,energy-saving and high-efficiency, and the power is sufficient for the 30% throttle to be excavated normally.
The seat rotates at any time during the excavation load exchange,and the line of sight is wide and easy to operate.
The chaissis part adopts the Isuzu weight-increasing axle,the four-wheel drive is equopped with engineering tires,and the off-road performance is good.
5.
| Total weight | 1000kg | |
| Bucket capacity | 0.025m³ | |
| Working device type | backhoe | |
| Minimum radius of gyration | 1190mm | |
| Maximum excavation height | 2490mm | |
| Maximum excavation depth | 1400mm | |
| Maximum discharge height | 3300mm | |
| Engine | Capacity | |
| Engine Rated output power | 8.6 kw | |
| Maximum torque | 2880 r/min | |
| Maximum travel speed | 2 km/h | |
| Max. travel speed | 25km /h | |
| Maximum gradeability | 25° | |
| Maximum Digging Force | 6.5 kn | |
| Maximum depth cleaning | 345mm | |
| The maximum height of land clearing | 255mm | |
| Pump type | Gear pump | |
| Working pressure | 16Mpa | |
| Flow | 21.6 L/min | |
| Hydraulic oil capacity | 17.4 L | |
| Engine oil capacity | 1.65L | |
| Fuel tank capacity | 7.35 L | |
