- Power(W):
- 5.5HP
- Dimension(L*W*H):
- 750*460*700mm
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support, Online support
- Condition:
- New
- Application:
- road Machinery
- Power Type:
- gasoline,diesel
- Brand Name:
- LH
- Place of Origin:
- Shandong, China
- Certification:
- ISO
- Machine Type:
- Plate Compactor
- Product name:
- small 90kg flat vibratory plate compactor capacity for sale
- Weight:
- 90KG
- Fuel tank:
- 3.6L
- Max. speed:
- 3600rpm
- Work efficiency:
- 660m3/hr
- Speed:
- 4cm/s
- Exciting force:
- 13kN
- Centrifugal deep:
- 30cm
- Frequency:
- 5500vpm
- PACKAGE SIZE:
- 85*50*110cm
- Supply Ability:
- 1000 Set/Sets per Month small 90kg flat vibratory plate compactor capacity for sale
- Packaging Details
- standard wooden box for small 90kg flat vibratory plate compactor capacity for sale
- Port
- qingdao/dalian/shenzhen/ningbo
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 10 >10 Est. Time(days) 15 To be negotiated
Introduction for small 90kg flat vibratory plate compactor capacity for sale :
Vibrating plate compactor is mainly suitable for the bonding between tamping particles and materials with less friction, such as river sand, gravel and asphalt. Under normal circumstances, the floor area of the same type of flat plate is similar, so the performance of the flat impact cymbal is mainly affected by the quality of the whole machine, the exciting force and the excitation frequency. The exciting force is mainly used to maintain the forced vibration of the material to be compacted; and the excitation frequency affects the compaction efficiency and the degree of compaction. That is, under the same exciting force, the higher the excitation frequency, the higher the compaction efficiency and compactness high.
The vibrating plate compactor needs to maintain a certain jump height when the work jumps, generally between 0.4-0.8mm. When the vibrating plate compactor reaches the same exciting force, the higher the operating frequency of the plate compactor, the smaller the required vibration quality, and the lighter the overall quality.
Featurers for small 90kg flat vibratory plate compactor capacity for sale :
*Foldable handle for easy transportation and stock. (straight handle is also available)
*Complete sealed belt cover to prevent sand and soil in.
*Built-in wheels for easy transport.
*Centrally mounted fully enclosed exciter for an even spread of compactive force over the whole base plate
*Throttle control for easy holding working speed. (Throttle control is available as optional)
*Heavy-duty shock mounts reduce vibration to the upper engine and handle.
*Rubber & canvas mat for brick paving compaction as option.
*Lifting Hook is available as optional
small 90kg flat vibratory plate compactor capacity for sale
We will send concrete vibrator plate compactor picture which you have orderd, then packing it with standard export wooden box after you have confirmed the machine is ok .
Different machines" package will be different. We usually supply export wooden box ,carton box package. If it is a big machine and production line machine , it will be loaded in the container directly .
