ABCDF EHOT-M1 Electric Hydraulic Manual Radiolucent Surgical Operating Table for Sale
1.the application of modern and humanism combined with the design concept, using electric imported hydraulic transmission technology,follow the development trend of the clinical operation,meet the image observation and diagnosis of the current operation process requirements.
2.product is easy to operate,strong versatility,wide application ,material selection, workmanship excellent,quality reached the international level.
3.Fully meet the general surgery,heart,kidney,thyroid,extracorporeal circulation,head and neck, gallbladder and pleura,department of urology,department of orthopedics, department of gynecology,rectum,spine surgical operation requirements.
| Technical Parameters | Technical Parameters |
Total Size: | (2015*540)±10mm |
Height adjustment range: | Min height: (650±20)mm Max height: (1000±20)mm(electric) |
Back section up: | 70±2°(electric) |
Back section down: | 32±2°(electric) |
Trendelenburg: | 25±2°(electric) |
| Re-trendelenburg: | 25±2°(electric) |
| Lateral tilt: | 22±2°(electric) |
Lifting route: | (350±20)mm(electric) |
Leg section adjustment: | rasied: 28±2° lower: 90±2°(manual) |
Head section adjustment: | rasied: 30±2° lower: 90±2°(manual) |
Table panel x-ray attenuation cofficient: | ≤0.76mmAL |
G.W. Of overall table: | 236kgs |
Wood carton packing volume: | 1430*750*1175mm |
| Voltage | 220V 50Hz or 110V,60HZ for choice |
ADVANTAGES AND CHARACTERISTICS:
1.The use of electric hydraulic transmission structure, stable speed, reliable performance;
2.CHOAR-GER electric hydraulic system and Germany gas spring
3.Carbon fiber is good for C-arm. Wider and thicker carbon fiber backboard good for C-arm
4.304 stainless steel base, high density memory mattress
5.Foot braking
6.No bridge function, but “V” and revised “V” function Replace that;
7.Double controllers
8.Battery is optional;
9.Besides of usual functions, it has one key reset function;
|
|
|
Usually The warranty is 1-2years due to different products, and We support lifetime maintaining.
A.Offer door to door service;
B.We send you free parts by courier and technical guidance by video/call;
C.We support you free training .
FAQ
A: We are manufacturer,we have our own R&D team and sales team,We provide you one-stop service.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q: What is your payment term?
1.L/C at sight;
2.T/T:30% deposit by T/T,70%balance by T/T before shipment
3.Trade term:EXW, FOBShanghai or CIF&CFR
Q: What is your min.order?
A: There"s no minimum quantity.
