1.The controller device lock key protecting from misoperation.
2.The table is made of penetrable X-ray material, there is cassette guide rail under the table which make radiography.
3.The table is fixed a button which can control the electric wheel to draw in and put out so that the table can be pulled easily.
4.Accessories and guide rail are made of stainless steel, polyurethane material etc.
5.The main accessory hydraulic pump and electromagnetic value are made of imported component from Taiwan.
6.The mattress is made of form polyurethane, acid and alkali resistance, hight emperature resistance and easy clean.
7.The head board and leg board are adopted special imported gas-spring from Germany, it’s convenient operate.
1.) polyurethane mattress(ps:detachable)
2.) C-arm, back section up and down controlled by electric
3.) electric hydraulic system
Table positions:
Degrees from horizontal
Offer Backup Battery in case of no power or malfunctioning.
Controllable global movements to include up/down, forward/back, left/right and
Trendelenburg and reverse Trendelenburg.
Hand control - remote control
Lateral bars (siderail) all along the table to hook for surgical accessories.
Patient complete fasten accessories.
Accessories for orthopedic extension, upper and lower limbs.
Accessories for gynecology surgery
Power requirements: main and Battery
Standard Accessories:
Arm support:1pair
Leg support:1pair
Shoulder support:1pair
Waist support:1pair
Anesthetic acreen:1pc
Belt:1pc
| Total Size | 1960*480mm |
| Height adjustment range | 690-930mm |
| Back section up | 75° |
| Back section down | 10° |
| Trendelenburg | 20° |
| Re-trendelenburg | 25° |
| Lateral tilt | 18° |
| Leg section adjustment | Up 45° Down 90°(ps:detachable) |
| Kidney bridge elevation | ≥80mm |
| Head section adjustment | Up 45° Down 50°(ps:detachable) |
| G.W. Of overall table | 270kgs |
| Wood carton packing volume | 1750×750×900mm |
| Voltage | 220V 50Hz or 110V,60HZ for choice |
