15 micro inverters need to be equipped with a monitor!
| SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor |
| High efficiency,reliability,stability for Frequency Inverter Single Phase Motor |
| Good heat-dissipation,low noise.Customer orientid service.Flexible design,easy to customize. |
| Innovation & smart monitoring.Convenient operation.Easy to install |
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
Advantages of Frequency Inverter Single Phase Motor
1.Peak Inverter Efficiency 95.5% ,CEC Weighted Efficiency 94.5%.
2.Long lifetime and increased reliavility.
3.Maximized energy harvest.
4.Reduced power loss with shade,dust and debris.
5.Simple design,with plug and play chain installation.
6.Improved safety with no high voltage hazards.Easy installation.
7.Constant remote monitoring at PV module level.
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
Model | SP-M248 | ||||
Input Data(DC) | |||||
Recommended input power | 160-300W | ||||
Maximum input DC voltage | 54V | ||||
Min./Max.Start Voltage | 26V/50V | ||||
Peak power tracking range | 26V~40V | ||||
Operating range | 22V~50V | ||||
Maximum DC short circuit current | 15A | ||||
Maximum input current | 10A | ||||
Output Data(AC) | |||||
Maximum output power | 248W | ||||
Nominal output current | 1.08A | ||||
Maximum output current | 1.11A | ||||
Nominal voltage range | 184V~265V | ||||
(Adjustable with Country Deviation) | |||||
Nominal frequency range | 46Hz~61.2Hz | ||||
(Adjustable with Country Deviation) | |||||
Power factor | >0.99 | ||||
Total Harmonic Distortion | <3% | ||||
Maximum units per branch | 15 | ||||
Peak inverter efficiency | 95.50% | ||||
CEC weighted efficiency | 94.50% | ||||
Nighttime power consumption | 120mW | ||||
Operating temperature range | -40oC~+85 oC | ||||
Dimensions (WxHxD) | 230mm*163mm*26mm | ||||
Weight | 1.6kgs | ||||
Communication | PLCC | ||||
Warranty | 15 Years | ||||
Enclosure environmental rating | IP65 | ||||
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor d
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design,
production and sales of electric equipments.Head office located in the largest manufacturing base
of electric equipment of Wenzhou China, which is called "the Electric Equiment Capital of China".
We have 5 specialized branches,over 300 specialized cooperative partners.Saip,an ISO9001 certificated enterprise.
With 20 years of development history, Zhejiang Saip Electric Co., Ltd. has become a modern
enterprise integrating the production,sale with research.
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
1,Material,size and other requirements are customized.
2,Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3,Answer your question detailed.
4,Solve the problem with you during using our products.
5,More our products you can visit our website.
SAIP/SAIPWELL Solar Energy System Micro Inverter On Grid Frequency Inverter Single Phase Motor
we can provide you good quality product and best service .we can design the product as your demmand and we also have other type of products for you to choose.
