SPECIFICATIONS
| Brand | Mingfa Tech | |
| Series Name | xLED Kits | |
| Seriest Number | xLED Kits-225 | |
| Manufacturing Technology | Cold forging | |
| Material | AL1070 | |
| Color & Finishing | Black Anodized & Clear Anodized | |
| Certification | CE, ROHS, WEEE | |
| Diameter(mm) | Φ225 | |
| Height(mm) | 60.0 | 100.0 |
| Item Number | xLED-22560 | xLED-225100 |
| Max. Lumen | 21000 Im | 28000 Im |
| Dissipated Power (Ths-amb,50°C) | 150.0 W | 200.0 W |
| Thermal Resistance Rth（°C/W) | 0.3°C/W | 0.2°C/W |
| Cooling Surface Area (mm²) | 673851 mm² | 1143659 mm² |
| Net Weight (g) | 2220.0 g | 3150.0 g |
| Quantity(pcs/CTN) | 6 pcs | 4 pcs |
| Modular Types | COB&SMD | COB&SMD |
| For Environments | Indoor area,Outdoor area | |
| For Lightings | High bay,Flood lights,Street lights,Horticulture lights,Area Lights | |
| For Application | Industrial & Warehouse, Horticulture, Outdoor | |
| For LED brands | Adura,Bridgelux,BJB,Citizen,Cree,Edison,GE,LG,Lumileds,Lumens,Luminus,Ledil,Nichia, Osram,Philips,Prolight Opto,Samsung,Seoul,Sharp,Tridonic,Vossloh Schwabe,Xicato,Zhaga | |
