9V 1A led strip light power supply dc ups 9v rechargeable battery ups power

Click on the image to view the original image

Product：	views：129V 1A led strip light power supply dc ups 9v rechargeable battery ups power
Branch：	WGP
Type：	ONLINE, 9V 1A mini ups
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 18:49

Product Details

Overview

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: WGP

Model Number:: UPS901A-09

Phase:: Single Phase

Protection:: Overvoltage

Weight:: 153G

Output Voltage:: 9V

Type:: ONLINE, 9V 1A mini ups

Application:: security,networking,telecommunication,minitoring,alarm

Capacity:: 16.28wh/2200mAh

Input:: Volt:9.2V±5%,current:350mA+loading current

Output:: Volt:9.2V±10%,current ≤1000mA

Material:: ABS

Battery Type:: Lithium Ion Battery

Backup time:: 2~8hours

Net Weight:: ≤153g

Size:: 111*60*26mm

Product name:: 9V 1A led power supply dc ups 9v rechargeable battery ups power

Supply Ability

Supply Ability:: 5000 Piece/Pieces per Quarter

Packaging & Delivery

Packaging Details: Carton packing
Size: 42 x 23 x 24 cm
Qty: 44pcs/carton
Weight: 11kg/carton

Port: Shenzhen

Lead Time:: 7 working days after payment

9V 1A led power supply dc ups 9v rechargeable battery ups power

Product Features

DC 9V Mini UPS Tecnical Features :

Mini UPS uninterruptible power supply is a standby energy storage power supply.

Used safe and environmental lithium cells, credible and stable PCB, trickle/constant-current/ constant-voltage lithium battery charging BMS,

Created by high performance and efficiency DC-DC, boosting and switching circuit. This mini UPS with perfect over-charged, over-discharged, over-current and short-circuit protection.

Specifications

DC 9V Mini UPS Basic Information
Model	UPS901A
Capacity	16.28wh/2200mAh
Battery Type	18650 lithium ion battery
Input Voltage	9.2V ±5%
Input current	350mA+loading current
Output Voltage	9.2V±10%
Output current	≤1000mA
Discharging transfer efficiency	≥85%
Over-discharged protection(battery)	6.0V( Over-discharged release 6.3V)
Over-charged protection(battery)	8.5V( Over-charged release 8.25V)
With load current(battery)	≥1000mA
Working temperature	-20°C~85°C
Weight	≤153g
Size	111x60x26mm
Warranty	1 year
Certification	CE,ROHS,FCC,PSE

Buying Guides

Product Overview

Packaging & Shipping

Packing Method
1. Well protection neutral box packing
2. 44PCS/CTN
3. CTN Size:422324CM
4. G.W 11kg
Packing Include
UPS Battery	1PC
DC Cable	1PC
User Manual	1PCS
Delivery Time
Sample	2-3 working days
Bulk Order	15-20 working days
Shipping Method
DHL,UPS,FedEX,EMS,HongKong Post,Swiss Post etc....
