Measuring range: AC70V-500V
Power supply range:AC70V-500V
The highest input: AC500V. Note: The input voltage higher than 500V may be permanently damaged!
Allowable error: ±1%;
Input impedance: > 1 mΩ
Operating current: < 23mA
Refresh rate: about 300mS
Display mode: three "0.56" LED digital tubes
Display color: red
Lead length: 15cm
Dimensions: 48 x 29 x 22 mm, length X width X thickness;
Opening size: 46 x 27 mm
Net weight: 18g
Gross weight: 25g
Working temperature: -20°C~65°C
