 | Model | RZ-8023 |
| Working voltage | 5-30V DC | |
| Static current | < 30uA | |
| Current output | 6A | |
| Maximum load | 10A | |
| Operating temperature | -20° ~ +50° | |
| Output mode | Induced voltage output | |
| Delay Time Range | 15s-5min, Adjustable time delay | |
Sensing method | inactive mode | |
| detection angle | 145° coning angle | |
| sensing distance | 5-7m | |
| size | 49*42.5 |
Product features
1. Load power above 18W
2. Small size and convenient installation
3. High stability and long induction distance
4. Dc-dc plug, convenient connection
5. Low power consumption
The human sensor switch, when people go into its detection distance, detect the movement of the human body, switch on, when people leave the sensor range it will be closed in the delay time.
Range of application
1. When people come to output, the delay will be automatically closed after people leave.
2. It is suitable for automatic lighting of corridors, corridors, toilets, basements, warehouses, garages and other places, automatic ventilation of exhaust fans and automatic control of other electrical appliances and other functions.
3. Random delay: 16 seconds (can be customized according to customer requirements, customized range from 2 seconds to 120 minutes)
4. Temperature compensation: special temperature compensation chip reduces the influence of temperature on the induction distance.
5. Trigger mode: can be triggered continuously
