New 3014 PIR T8 Human Sense led tube, 9w/14w/18w led tube with sensor
Led Tube
New Type T8 Human Sensor Tube
I. Sensing Principle and method
In the nature, everything when its temperature is higher than absolute temperature(-273) will generate Infrared ray, things of different temperature can generate different wavelength of infrared. This product use pyroelectric infrared sensor(PIR) to sense the infrared and it can transform 8-12μ M infrared signal into electric signal.
Also equipped with Fresnel lens which can make the signal more accurate. It can reflect and refract the Signal onto PIR, so that PIR can generate more powerful electric signal, then CUP will transform the signal into PWM signal and transfer to control IC to determine the brightness and on/off of the light.
Sensing method 1:
1. Switch on the l ight, the light wi l l be ful l brightness, after 30s-60s, the light will become 30% brightness(adjustable), maintain 60s.
2. If the light sense human body during 30% brightness, the light will become full brightness and delay for 30s; If not, the l ight will be off.
3. If the light sense human body when the light is off, the light will become
Full brightness for 30s. After that the light will become 30% brightness for 60s. After this the light will work cycl ing between 1~2.
Sensing method 2:
1. Switch on the light, the light will be full brightness, after 30s-60s, thelight will become 30% brightness(adjustable), maintain 60s.
2. If the l ight sense human body during 30% brightness, the light will become full brightness and delay for 30s; If not, the light will maintain the 30% brightness.
Sensing distance:
A>Vertical 7-8m, B>Horizontal 5m, C>Angle: 120°
II. Structure and Application
1. The main-body use high-purity aluminum alloy(AL6063) as the material, with electrostatic spraying cover, also under constant temperature curing, to make the the adhesive force of spraying cover more powerful.
2. High light output, wide beam angle.
3. Apply in indoor decoration, passage, garden, garage, mall, hospital and the place where need long time lighting.
III. Technical Parameter
| Rated Voltage | AC 100-265V 50/60Hz | Waterproof | Non-waterproof |
| Rated Power | 9W/14W/18W | LED Quantity | 84/144/168 pcs |
| Beam Angle | >120° | Working Temperature | -20~40°C |
| Lens | PC Clear/PC Mi lky/Wave | Protection Against Electric Shock Level | II |
| Base | T8 |
Dimensions (Unit: mm/inch)
Production of flowsheet:
1) What are the best selling products in Signcomplex?
- tube
- panel lights
- LED strips
- spot and bulb
- controllers
2) What will be porducts Signcomplex develop for the next year?
Signcomplex is devoted to innovation in the lastest LED technlogy. We never stop researching new LED lights since the establishment. We keep the valued customers posted of newsletters on the development every week. You can get the news after subscribing in our mail list.
3) What is the main market for Signcomplex?
We are selling more to EU and north America because the markets have high quality standard for LED products. The rate stands our turnover up to 70-80%. But other new markets are increasing demand of the new LED technology. We are also optimistic about the markets for other American and Asian regions.
4) What LEDs do you usually use for your LED products?
For high power LED luminaires we mainly use Cree and Edison LEDs, We use some Philips as well. we also consider to use more multi-chip LED brands like Bridgelux and Sharp, as the multi-chip technology will be intensively used by manufacturers.
5) What is Signcomplex lead time?
Usually we ship orders in 2 weeks. But it will take a little longer if with heavy burden of production task. It also takes more time with customized products.
6) Can Signcomplex do custom assembly or offer OEM product?
Signcomplex has gained a lot of experience on OEM assembly of LED strip lighting. The strips can have different size, layout, customer logos and labels. We also want to apply the experience to LED luminaires as we have good design and engineering team. Because we have our own CNC processing machines we can quickly work out prototype for LED fixtures, especially for LED bulbs and spots. We will strictly follow the principal that we won’t disclose or sell customer unique designs or jointly developed products to another third party.
7) Do you have warranty for products?
Yes, we have 3 and 5 years warranty for different kinds of products. During the period, if customers have the approval showing product quality issues and if certified by Signcomplex engineers, we would request customers to ship back the failure parts and replace new items with the transportation charged being paid by us.
8) Does Signcomplex design its products?
Yes, Signcomplex designs and assembles all the products we are selling. Our engineers have abundant knowledge of optics, electronics, mechanical and thermal management, as well as light control technology. Some of them have successful experience to design lighting products for world famous brands. Our basic principle to design internal driver and circuit is safety under EMC/UL list possibility and reliability.
9) How to buy Signcomplex products?
In most case we sell directly to customers worldwide, however we have already set up distribution partners in those countries. For the details please refer to "Contact Us".
Customers in these countries can get Signcomplex products from the authorized distributors. In other countries and regions customers can directly contact Signcomplex sales team by writing to our email address or make a call. We will respond with quick service maximum within 12 hours.
10)Which kind of dimmer can be used on the Signcomplex dimmable lamps?
