100w AC solar power system with 300w solar inverter solar energy system
| Model NO. | PV-SP-159 | ||
| Solar panel | 100W 18V with 5m Cable | ||
| Lead acid battery | 12V 50AH | ||
| Inverter | modified sine wave 300W | ||
| Ac out put | 120v/240v 1pcs | ||
| DC output | (12V/5A)8piece,(USB 5V/50MA)2piece | ||
| Charging time | 18hours by solar panel | ||
| working time | 9hours(1-4pcs 5W DC LED bulb ) | ||
| Product Size | 300*180*240mm N/W:36.9kg, G/w:35.2kg | ||
| Accessories | 4pcs 3w,12v led bulb and 5 in 1 multifunctional USB date cable |
Model: 5W
Solar power: Crystalline solar panel 5W 18V
Battery: Lead Acid Battery 12V 4AH
Product size: 100 * 120 * 145mm
Product Weight: 4.32kg
Product Weight: 2.95kg
Charging time: 5W solar panel charge takes 18 hours (based on the average sunshine time and sunlight intensity in different parts of the decision)
Working Hours: 1-4pcs 3W DC LED light bulbs at least 8-10 hours; (based on actual output power of electrical equipment decision)
Function: battery charge and discharge over-charge and over-discharge protection; overload, short circuit protection when using electrical equipment, fuses (5A) has overcurrent protection circuit
Standard configuration:
3W DC bulb 2 with 3 noodle
Model: 10W
Solar panel: polycrystalline silicon solar panel 10W 18V
Battery: Lead Acid Battery 12V 7.2AH
Product size: 198 * 97 * 145mm
Product Weight: 5.3kg
Product Weight: 4.5kg
Charging time: 10W solar panel charging requires 18 hours (based on the average sunshine time and sunlight intensity in different parts of the decision)
Working Hours: 1-4pcs 3W DC LED light bulbs at least 8-10 hours; (based on actual output power of electrical equipment decision)
Function: battery charge and discharge over-charge and over-discharge protection; overload, short circuit protection when using electrical equipment, fuses (5A) has overcurrent protection circuit
Standard configuration:
3W DC bulb 2 with 3 noodle
18V 10W monocrystalline silicon solar panel with 5 noodle
Model: 50W
Solar panel: polycrystalline silicon solar panel 50W 18V
Battery: Lead Acid Battery 12V 24AH
Product size: 300 * 180 * 240mm
Product Weight: 17.6kg
Product Weight: 19.2kg
Charging time: 50W solar panel charging requires 18 hours (based on the average sunshine time and sunlight intensity in different parts of the decision)
Working Hours: 1-4pcs 5W DC LED light bulbs at least 8-10 hours; (based on actual output power of electrical equipment decision)
Function: battery charge and discharge over-charge and over-discharge protection; overload, short circuit protection when using electrical equipment, fuses (5A) has overcurrent protection circuit
Standard configuration:
5W DC bulb 2 with 3 noodle
18V 50W monocrystalline silicon solar panel with 5 noodle18V 10W monocrystalline silicon solar panel with 5 noodle
...
